Description
Built to Power. Born to Win.
The GIGABYTE GAMING 850GM PG5 is a 850W, 80 PLUS Gold, fully modular ATX 3.1 power supply built for modern gaming rigs. It provides stable, efficient, and ultra-quiet power with intelligent safeguards to ensure peak performance when the stakes are highest.
| POWER SUPPLY SPECIFICATIONS | |
|---|---|
| Model | GP-GME850GM PG5 |
| Type | Intel Form Factor ATX 12V v3.1 |
| Output Capacity | 850W |
| 80 PLUS Efficiency | Gold (90% at typical load) |
| Dimensions | 150 x 150 x 86 mm |
| COOLING & ELECTRICAL | |
| Fan Type | 135mm FDB Fan |
| PFC | Active PFC (>0.9 typical) |
| Input | 100-240 Vac, 50-60 Hz |
| Protections | OVP / OPP / SCP / UVP / OCP / OTP / NLO / SIP |
| CABLES & CONNECTORS | |
| Cable Type | Embossed, All black |
| Main Connectors | 1 x ATX/MB 20+4 Pin, 2 x CPU/EPS 4+4 Pin |
| GPU Connectors | 1 x PCI-e 16 Pin (12VHPWR), 4 x PCI-e 6+2 Pin |
| Peripheral | 8 x SATA, 4 x 4-Pin Peripheral |
