Description
- Features a Mini ITX form factor, matching the installation specifications of compact computer build components for seamless assembly of small-form-factor PC systems.
- Comes with a standard PCI-E5.0 graphics card extension cable, supporting the connection of PCI-E5.0 graphics cards to meet the needs of high-performance component configurations.
- Constructed with aluminum alloy material, forming a sturdy frame that maintains structural stability while keeping the chassis lightweight for easy placement and handling.
- Designed as the 5.0 version of the chassis model, incorporating updated design elements to align with the assembly requirements of modern computer hardware components.
- Provides a dedicated space layout for essential PC parts, facilitating organized wiring and component installation for routine build and upgrade tasks.
Specification:
| T9 5.0 version parameters | |
| Product model | T9-5.0 |
| Product size | 155mm (W) * 325mm (D) * 224mm (H) |
| Material | 4mm aluminum plate/1mm steel plate/20mm North American walnut wood |
| Hard drive slots | 2.5 SSD * 1/3.5 HDD * 1+2.5 SSD * 1 |
| Compatible motherboard | ITX |
| Front I/O port | Type-C * 1 |
| Power supply | SFX 100mm |
| Heat sink | 58mm-78mm |
| Graphics card | 202mm-310mm, standard PCI-E 5.0 adapter cable |
| Fan (optional) | Top 120mm * 1 |
| Weight | Net weight 3.85kg |
| High-concerned chemical | None |
| With Power Supply | No |
| With Fan | No |
| With Side Panel Window | No |
| Power Supply Mounted | Bottom |
| Dust Filters | Bottom |
| RGB Support | NO RGB |
| 140mm Fan Options | 0 |
| 120mm Fan Options | 1 |
| Hot-Swap Drive Bays | 0 |
| Internal 2.5" Drive Bays | 1 |
| Internal 3.5" Drive Bays | 1 |
| Max GPU Length | 310mm |
| Max CPU Cooler Height | 78mm |
| Max PSU Length | 100mm |
| Case Weight | 4kg |
| Case Size | 155mm(W) * 325mm(D) * 224mm(H) |
| Power Model | SFX |
| Chassis Type | Desktops |
| Front Ports | Type-C*1 |
| Application | Desktop |
| Form Factor | Mini-ITX |
| Material | Aluminum alloy |
| Model Number | T9 5.0 |
| Type | Horizontal |
| Series | T9 |
