Description
Intel Arc B580 Steel Legend 12GB OC
B580 SL 12GO
-
Clock: GPU / Memory
GPU Clock: 2800 MHz
Memory Clock: 19 Gbps -
Key Specification
Intel® Arc™ B580 Graphics
12GB 192-bit GDDR6
Intel® Xe2-HPG Architecture
Intel® Xe Super Sampling 2 (Intel® XeSS 2)
Intel® Xe Matrix eXtentions (Intel® XMX)
Microsoft® DirectX® 12 Ultimate
2x 8-pin Power Connectors
3x DisplayPort™ 2.1, 1x HDMI™ 2.1a -
Key Features
Polychrome SYNC
Triple Fan Design
Striped Ring Fan
Stylish Metal Backplate
Ultra-fit Heatpipe
Air Deflecting Fin
0dB Silent Cooling
Super Alloy Graphics Card
Specification:
|
Graphics Engine
|
- Intel® Arc™ B580 Graphics |
|
Bus Standard
|
- PCI® Express4.0 x8 |
| DirectX | - 12 Ultimate |
| OpenGL | - 4.6 |
| Memory | - 12GB GDDR6 |
|
Engine Clock
|
- 2800 MHz |
|
Intel® XMX Engines
|
- 160 |
| Memory Clock | - 19 Gbps |
| Memory Interface | - 192-bit |
| Resolution | - Digital Max Resolution: 7680 x 4320 |
| Interface | - 1 x DisplayPort 2.1 (Primary, up to UHBR13.5) - 2 x DisplayPort 2.1 (Up to UHBR10) - 1 x HDMI 2.1a |
| HDCP | - Yes |
|
Multi-view
|
- 4 |
|
Recommended PSU
|
- 650W |
|
Power Connector
|
- 2x 8-pin |
|
Accessories
|
- 1x Quick Installation Guide |
| Dimensions | - 298 x 131 x 51 mm, 2.6-slot |
|
Net Weight
|
- 959 g |
