Description
ROG Rapture GT-AX11000 Pro
GT-AX11000 Pro Tri-Band WiFi 6 gaming router, 2.5G port, 10G port, enhanced hardware, ASUS RangeBoost Plus, 5.9 GHz, Triple-level game acceleration, free network security and AiMesh support
- High-efficiency WiFi 6 – Ultrafast WiFi 6 tri-band boosts speeds up to 11,000 Mbps, with 160 MHz channels for better efficiency and throughput
- Expanded coverage – Exclusive ASUS RangeBoost Plus improves signal range and overall coverage
- Flexible networking ports – One 2.5G port and one 10G port can be configured for either WAN or LAN operation
- Extreme quad-core CPU power – High-performance WiFi chipsets and 64-bit 2.0 GHz quad-core CPU take wireless signal processing to the next level
- Triple-level game acceleration – Online gaming gets network prioritization every step of the way, from PC to game server
SPECIFICATION
Model Name
GT-AX11000 PRO
Network Standard
IEEE 802.11ax
IPv4
IPv6
Product Segment
AX11000 ultimate AX performance
AX technology
Yes
Data Rate
2.4GHz AX: 4x4 (Tx/Rx) 1024 QAM 20/40MHz, up to 1148Mbps
5G-1Hz AX: 4x4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps
5G-2Hz AX: 4x4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps
Antenna
External antenna x 8 (non-detachable)
Transmit/Receive
2.4GHz 4x4
5GHz-1 4x4
5GHz-2 4x4
Processor
2.0GHz quad-core processor
Memory
256MB NAND flash and 1GB DDR4 RAM
Boosts speed
OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth * The 160MHz bandwidth may be unavailable in the 5GHz band in some regions / countries due to regulatory restrictions.
Operating Frequency
Tri-band Wi-Fi: 2.4 GHz / 5 GHz-1 / 5 GHz-2
Ports
1 x 2.5 Gigabit WAN Port 1 x 10 Gigabit WAN/LAN Port 4 x Gigabit LAN Ports 1 x USB 3.2 Gen 1 Port 1 x USB 2.0 Port
Button
WPS Button, LED Button, Reset Button, Power Switch
LED Indicator
Power x 1 2.4G x 1 5GHz-1 x 1 5GHz-2 x 1 WPS x 1 10GE x 1 LAN x 1 WAN x 1
Power Supply
AC Input : 110V~240V(50~60Hz) DC Output : 19 V with max. 3.42 A ；19.5 V with max. 3.33 A
Package content
GT-AX11000 Pro WiFi Gaming Router RJ-45 Cable Power Adapter Quick Start Guide Warranty Card
Product Weight (g)
2180g
AiMesh
AiMesh
Primary AiMesh router
AiMesh node
Router APP
ASUS Router APP
Game
Game Boost/acceleration
Game Radar
WTFast
UU boost
ROG_First
OpenNAT (Game Profile)
Alexa
Support Alexa skill
AiProtection
AiProtection Pro
Router Security Assessment
Malicious site blocking
Two-Way IPS
Infected Device Prevention and Blocking
Parental Control
Parental Control
Parental Control Customized Internet schedule
Maximum Parental Control profile : 64
Maximum Parental Control content filter rule : 64
Traffic Control
Adaptive QoS
Bandwidth Monitor
Bandwidth limiter
Maximum Bandwidth limiter rule : 32
Traditional QoS
Traffic Monitor
Real-time traffic monitor
Wired Traffic Monitor
Wireless Traffic Monitor
Traffic Analyzer
Traffic analysis period : Daily, Weekly, Monthly
Website history
Wireless
IPv6
MU-MIMO
WiFi Encryption : WPA3 Personal, WPA2 Personal, WPA Personal, WPA Enterprise, WPA2 Enterprise, Open System
UTF-8 SSID
Guest Network
Maximum Guest Network rule : 2.4 GHz x 3, 5 GHz-1 x 3, 5 GHz-2 x 3
Guest Network Connection time limit
Guest Network Encryption : Open system, WPA/WPA2-Personal/WPA3-Personal
WPS
Wi-Fi MAC address filter
Maximum MAC filters : 64
Wireless scheduler
Airtime fairness
RADIUS Client
Universal beamforming
WAN
Explicit beamforming
Internet connection Type : Automatic IP, Static IP, PPPoE, PPTP, L2TP
Dual WAN
WAN Aggregation
3G/4G LTE dongle
Android tethering
Port forwarding
Maximum port forwarding rule : 64
Port triggering
Maximum port triggering rule : 32
DMZ
DDNS
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
Let's Encrypt
Safe browsing
DNS-over-TLS
