Description
Optimised for Static Pressure
During the development of the new P8, special emphasis was placed on a focused airstream and thus a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Therefore, the P8 is particularly suitable for use on heatsinks and radiators.
High-Quality Bearing
Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan.
Maximum Quietness, Minimum Vibration
Even at low speeds, the operating sound of the new ARCTIC motor is barely noticeable. Due to sinus-magnetizing, the new motor only creates about 5 % of the vibration from the commutation of a regular DC motor without a filter. Consequently, there is no need for rubber spacers due to the steady and smooth torque of the new motor.
Two-Way Installation
- Push warm air out of the case
- Pull cool air into your case
Specifications:
| PERFORMANCE | |
|---|---|
| Fan Speed | 3000 rpm |
| Airflow | 23.4 cfm | 39.76 m³/h |
| Static Pressure | 1.90 mm/H²O |
| Noise Level | 0.3 Sone |
| FAN SPECIFICATIONS | |
| Frame & Control | Standard Frame / Fixed Speed |
| Connector | 3-Pin Connector |
| Bearing Type | Fluid Dynamic Bearing |
| ELECTRICAL CHARACTERISTICS | |
| Voltage | 12V DC (Typical) / 0V (Starting) |
| Current | 0.14 A |
| Cable Length | 400 mm |
| PHYSICAL SPECIFICATIONS | |
| Dimensions | 80 x 80 x 25 mm |
| Weight | 81 g |
