Description
The FZ12R BK is a powerful and reliable 120mm cooling fan engineered for efficient airflow, quiet operation, and long-lasting performance. Equipped with hydraulic bearings, it delivers smooth, stable rotation while extending lifespan for continuous system cooling.
With a variable speed range of 600–1600 RPM (±10%), this fan adapts dynamically to your system’s thermal demands via its 4-pin PWM connector, ensuring optimal cooling when you need it and quieter operation when you don’t. It produces a strong 66.53 CFM airflow while maintaining a controlled noise level of just 34.2 dB(A) max, making it ideal for gaming rigs, workstations, and performance builds.
Designed in a standard 120 × 120 × 25 mm form factor, the FZ12R BK fits most PC cases and radiators with ease. Backed by an impressive MTTF of ≥20,000 hours at 25°C and a 2-year warranty, it offers dependable cooling you can trust.
| Model NO. | FZ12R BK |
| Bearing Type | Hydraulic bearings |
| Speed | 600-1600 RPM+10% |
| Air Flow | 66.53 CFM |
| Dimension | 120(L)x120(W)x25mm(H) |
| Noise Level | 34.2dB(A)(MAX) |
| MTTF | ≥20000h Room Temp:25°C |
| Warranty | 2 Years |
| Fan | Connector: PWM 4PIN Rated Voltage: FAN:12V Rated Current: FAN:0.19A Power Consumption: FAN:2.28W |
