Description
SPECIFICATION
- PROCESSOR: AMD Ryzen™ 9 7940HS Mobile Processor
- DISPLAY: 14-inch, QHD+ 16:10 (2560 x 1600, WQXGA)
- MEMORY: 16GB DDR5 on board / 16GB DDR5-4800 SO-DIMM
- STORAGE: 1TB PCIe® 4.0 NVMe™ M.2 SSD (2230)
- GPU: NVIDIA® GeForce RTX™ 4070 Laptop GPU
- OS: Windows 11 Home
- COLOR: Black
ROG INTELLIGENT COOLING
Powerful hardware requires robust cooling, especially in a compact chassis. The Zephyrus G14 packs a vapor chamber for the CPU and GPU with Thermal Grizzly’s liquid metal thermal compound for ultra-efficient heat transfer from the hottest parts of the machine. With coverage of 48.2% of the heat generating components, the vapor chamber allows the G14 to have a 25W higher power budget, pushing performance to the limit without increasing fan noise or chassis size.
In the Silent operating mode during low power tasks, 0dB technology allows the fans to be automatically disabled for a truly silent experience.
In the Silent operating mode during low power tasks, 0dB technology allows the fans to be automatically disabled for a truly silent experience.
Endless personalization
Make the Zephyrus G14 uniquely yours with customizable animation options. Display text messages or system notifications, set the matrix to respond in real time to your audio source, or create a custom animation of your very own.
SPECIFICATION
| Marketing Name | ROG Zephyrus G14 |
| Color | Eclipse Gray Mini-LED version |
| Dimension (W x D x H) | 31.2 x 22.7 x 1.95 ~ 2.05 cm (12.28" x 8.94" x 0.77" ~ 0.81") |
| Weight | 1.72 Kg ( lbs) |
| Processor | AMD Ryzen™ 9 7940HS Mobile Processor (8-core/16-thread, 16MB L3 cache, up to 5.2 GHz max boost) |
| Chipset | TBD |
| Discrete/Optimus | MUX Switch + NVIDIA® Advanced Optimus |
| Graphic | NVIDIA® GeForce RTX™ 4070 Laptop GPU |
| Graphic Wattage | ROG Boost: 2030MHz* at 125W (1980MHz Boost Clock+50MHz OC, 100W+25W Dynamic Boost)* *The testing conditions were set in a laboratory environment with a controlled ambient temperature of 25±2°C. Results were obtained by testing with FurMark. Real world performance may vary. |
| Graphic Memory | 8GB GDDR6 |
| IGPU | AMD Radeon™ Graphics |
| Panel Size | 14-inch |
| Resolution | QHD+ 16:10 (2560 x 1600, WQXGA) |
| Refresh Rate | 165Hz |
| Response Time (G2G) | 3ms |
| Viewing Angle | 170/170 |
| Panel Tech | Mini LED |
| Brightness | 600 |
| Contrast | 100000:1 |
| DCI-P3 % | 100% |
| Anti glare | Anti-glare display |
| Adaptive-Sync technology | G-Sync |
| Pantone | Pantone Validated |
| Nebula Display | ROG Nebula HDR Display |
| Support Dolby Vision HDR | Yes |
| On board memory | 16GB DDR5 on board |
| DIMM Memory | 16GB DDR5-4800 SO-DIMM |
| Total System Memory | DDR5 32GB |
| Memory Slot | 1x SO-DIMM slot |
| Memory Max. | 32GB |
| Multi-channel memory technology | Support dual channel memory |
| System Storage Installed | 1TB PCIe® 4.0 NVMe™ M.2 SSD |
| M.2 slots support either SATA or NVMe | 1 |
| M.2 SSD Support List | 1TB M.2 NVMe PCIe 4.0 SSD 512GB M.2 NVMe PCIe 4.0 SSD |
| Expansion Slot (includes used) | 1x DDR5 SO-DIMM slot 1x PCIe |
| LAN | N/A |
| Wi-Fi/Bluetooth | Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.3 Wireless Card (*Bluetooth® version may change with OS version different.) |
| I/O Ports | 1x Type C USB 4 support DisplayPort™ / power delivery 1x USB 3.2 Gen 2 Type-C support DisplayPort™ 2x USB 3.2 Gen 2 Type-A 1x card reader (microSD) (UHS-II) |
| Display output | 1x HDMI 2.1 FRL |
| Audio | 1x 3.5mm Combo Audio Jack |
| Webcam | 1080P FHD IR Camera for Windows Hello |
| Mic | Built-in 3-microphone array |
| Keyboard Type | Backlit Chiclet Keyboard 1-Zone RGB |
| NumberPad | N/A |
| Aura Sync | Yes |
| Speakers | 4-speaker system with Smart Amplifier Technology |
| Audio Tech | AI noise-canceling technology Dolby Atmos Hi-Res certification Smart Amp Technology |
| Operating System | Windows 11 Home |
| Office | Office Home and Student |
| Antivirus | MCAFEE_30D |
| Xbox Game Pass | Xbox Game Pass for PC_3 months (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass for PC. Eligible markets are determined at activation. Game catalog varies by region, device, and time.) |
| Security | BIOS Administrator Password and User Password Protection Trusted Platform Module (Firmware TPM) |
| Battery | 76WHrs, 4S1P, 4-cell Li-ion |
| Fast charging | Recharge from 0-50% in 30 minutes |
| Power | ø6.0, 240W AC Adapter, Output: 20V DC, 12A, 240W, Input: 100~240C AC 50/60Hz universal |
