Description
ASUS ROG Strix B850-G Wifi DDR5 Gaming Motherboard
Unleash next-gen performance with the ROG Strix B850-G Gaming WiFi. Built with a sleek white PCB and featuring support for AMD Ryzen™ 9000 Series processors and cutting-edge DDR5 memory, this motherboard is equipped for top-tier gaming. PCIe® 5.0, USB 20Gbps Type-C® and WiFi 7 ensure unmatched speed and performance.
Specification
| Model | ROG STRIX B850-G GAMING WIFI | ||
| CPU & CHIPSET | |||
| Socket | AMD AM5 (Ryzen™ 9000, 8000, 7000 Series) | ||
| Chipset | AMD B850 | ||
| MEMORY | |||
| Slots | 4 x DIMM, Dual Channel | Max Capacity | 256GB DDR5 |
| OC Support | Up to 8000+ MT/s (EXPO™, AEMP) | ||
| ECC Support | Yes (Non-ECC unbuffered with On-Die ECC) | ||
| GRAPHICS | |||
| Display Outputs | 1 x HDMI 2.1 (4K@60Hz), 1 x DisplayPort 1.4 (8K@30Hz) | ||
| EXPANSION | |||
| PCIe Slots | 1 x PCIe 5.0 x16 Ryzen 8000 runs in PCIe 4.0 x8/x4 mode |
||
| STORAGE | |||
| M.2 Slots |
|
||
| SATA Ports | 2 x SATA 6Gb/s | ||
| RAID Support | RAID 0/1/5/10 (varies by CPU) | ||
| NETWORKING | |||
| Ethernet | Intel® 2.5Gb LAN with ASUS LANGuard | ||
| Wireless | Wi-Fi 7 (2x2, 2.4/5/6GHz) + Bluetooth 5.4 | ||
| USB PORTS | |||
| Rear |
|
||
| Front |
|
||
| AUDIO | |||
| Codec | Realtek ALC1220P, 7.1 Surround, SupremeFX, Savitech AMP | ||
| Features |
|
||
| BACK PANEL I/O | |||
|
|||
| INTERNAL I/O | |||
|
|||
| SPECIAL FEATURES | |||
| Q-Design | M.2 Q-Latch, Q-Release for PCIe and DIMM, Q-Antenna, Q-LED | ||
| Cooling | VRM & M.2 Heatsinks | ||
| DIY Features | Pre-mounted I/O, BIOS FlashBack™, Clear CMOS, SafeSlot | ||
| RGB | Aura Sync, ARGB Gen2 Headers | ||
| SOFTWARE | |||
| ROG | ROG CPU-Z, Dolby Atmos | ||
| ASUS Apps | Armoury Crate, Aura Creator, Fan Xpert 4, GameFirst, AI Advisor, GlideX, TurboV Core, DriverHub | ||
| 3rd Party | AIDA64 (60 days), HWiNFO, Norton 360 (60 days), WinRAR (40 days) | ||
