Description
SPECIFICATION
| GPU Engine Specs | CUDA Cores: 10752 |
| Boost Clock (MHz): 2617MHz | |
| Base Clock (MHz): 2295MHz | |
| Thermal and Power Spec | Minimum System Power Requirement (W): 850W |
| Supplementary Power Connectors: 3x PCIe 8-pin cables (adapter in box) OR 1x 450 W or greater PCIe Gen 5 cable |
|
| Memory Specs | Memory Clock: 30Gbps |
| Standard Memory Config: 16GB | |
| Memory Interface: GDDR7 | |
| Memory Interface Width: 256-bit | |
| Memory Bandwidth (GB/sec): 960 GB/sec | |
| Feature Support | Real-Time Ray Tracing : Yes |
| Ray Tracing Cores: 4th Generation, 171 TFLOPS | |
| Tensor Cores: 5th Generation, 1801 AI TOPS | |
| NVIDIA Architecture: Blackwell | |
| Microsoft DirectX: 12 Ultimate | |
| NVIDIA DLSS: 4 | |
| NVIDIA Ansel: Yes | |
| NVIDIA FreeStyle: Yes | |
| Bus Support: PCI Express Gen 5 | |
| NVIDIA ShadowPlay: Yes | |
| OS Certification: Windows 11 / 10, Linux, FreeBSDx86 | |
| NVIDIA Highlights: Yes | |
| NVIDIA G-SYNC™-Ready: Yes | |
| Game Ready Drivers: Yes | |
| NVIDIA Studio Drivers: Yes | |
| NVIDIA GPU Boost™: Yes | |
| Vulkan API :1.4 | |
| OpenGL: 4.6 | |
| NVIDIA Encoder: 2x Ninth Generation | |
| NVIDIA Decoder: 2x Sixth Generation | |
| Graphics Card Dimensions | Length: 300mm Height: 116mm Width: 41mm |
| Display Support | Multi Monitor: up to 4 Maxmium Digital Resolution: 4K at 480Hz or 8K at 165Hz with DSC HDCP: 2.3 Standard Display Connectors: 3x DisplayPort 2.1b, 1x HDMI 2.1b |
