Description
Where Style Meets Function
Designed for an exceptional view, The CTE E550 TG Gravel Sand is a dual chamber mid-tower chassis with three TG panels that allows users to display components in style. It supports the latest Hidden-Connector motherboards and offers a three-way GPU installation option, seamlessly blending aesthetics with compatibility. It also excels in cooling support, accommodating up to a 420mm AIO radiator on the M/B side, and up to eight 120mm fans (six 140mm fans) can be installed in the chassis. Combining aesthetics with compatibility, the CTE E550 TG Gravel Sand is the perfect choice where style meets function.
Specifications:
| Series | CTE |
| Case Type | Mid Tower |
| Dimensions | 558.5 x 270 x 513mm (21.99 x 10.63 x 20.2 inch) |
| Weight | 14.5 kg / 31.97 lbs. |
| Side Panel | 4mm Tempered Glass x 3 |
| Color | Black |
| Material | SPCC |
| Drive Bays | 3 x 3.5”, 1 x 2.5” or 2 x 3.5”, 2 x 2.5” |
| Expansion Slots | 7 |
| Motherboard Support | Mini ITX, Micro ATX, ATX, E-ATX (up to 12” x 10.5”) |
| I/O Port | USB 3.0 x 2, Type-C x 1, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| Fan Support | Top: 2 x 120mm, 1 x 120mm Right (M/B Side): 3 x 120mm / 2 x 120mm / 1 x 120mm Right (M/B Side): 3 x 140mm / 2 x 140mm / 1 x 140mm Bottom: 3 x 120mm / 2 x 120mm / 1 x 120mm Bottom: 3 x 140mm / 2 x 140mm / 1 x 140mm |
| Radiator Support | Top: 1 x 240mm, 1 x 120mm Right (M/B Side): 360mm / 240mm / 120mm, 420mm / 280mm / 140mm Bottom (DIY only): 360mm / 240mm / 120mm, 420mm / 280mm / 140mm |
| Clearance | CPU cooler max height: 166mm VGA max length: 415mm (with radiator), 443.8mm (without radiator) PSU max length: 220mm |
