| Usable Capacities |
500GB |
| NAND Components |
3D NAND |
| Interface |
PCIe Gen 3x4 NVMe 1.3 |
| Form Factor |
M.2 2280 |
| Package Dimensions (L×W×H) |
123 x 85 x 4.3 mm |
| Product Dimensions (L×W×H) |
22 x 80 x 2 mm |
| Weight |
6.6g |
| Max Sequential Read* |
500G: Up to 2200MB/s |
| Max Sequential Write* |
500GB: up to 1200MB/s |
| TBW |
500GB: 110 |
| PCIe Link Power Management |
APST, ASPM, L1.2 |
| Operating Temperature |
0°C to 70°C |
| Storage Temperature |
-40°C to 85°C |
| Certifications |
BSMI, CE, FCC, KCC, VCCI, REACH, RoHS |
| MTBF |
2 Million Hours |
| Error Correction Code |
Less than 1 sector per ten quadrillion bits read |
| Product Health Monitoring |
Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T) |
| Full End-to-End Data path protection |
Supported |
| Performance Optimization |
TRIM (requires OS support) |
