Description
The Arctic P8 Max High-Speed 80mm PWM Fan delivers powerful cooling in a compact size, featuring a wide speed range of 500–5,000 RPM for maximum flexibility and performance. With high static pressure of 5.3 mm H₂O and airflow up to 40 CFM, it is perfect for tight cases, heatsinks, and radiators that demand efficient airflow. Its PWM-controlled 0 dB mode allows the fan to stop completely at low loads for silent operation, while the fluid-dynamic bearing ensures long-lasting, quiet performance. Built for reliable, high-performance cooling in small spaces, the P8 Max is ideal for SFF builds and demanding environments where strong airflow is needed without sacrificing low-noise operation.
Specifications:
| Performance | |
| Fan Speed | 800 rpm |
| Airflow | 46 cfm | 78 m³/h |
| Static Pressure | 0.45 mmH2O |
| Noise Level | 0.08 Sone |
| Fan | |
| Fan Frame | Standard |
| Control Type | Fixed Speed |
| Connector | 3-Pin Connector |
| Fan Bearing | Fluid Dynamic Bearing |
| Operating Ambient Temperature | 0—40 °C |
| Electric Characteristics | |
| Typical Voltage | 12 V DC |
| Starting Voltage | 7 V |
| Current | Voltage | 0.11 A | 12 V DC |
| Cable Length | 400 mm |
| Size & Weight | |
| Length | 140 mm |
| Width | 140 mm |
| Height | 27 mm |
| Weight | 180 g |
