24B36H
23.8" 100Hz IPS Monitor
24B36H is a Full HD display with IPS wide viewing angle, Incredible, 100Hz refresh rate, and 1ms response time, upgraded 3-Sided Frameless, mega DCR. This IPS display deliver 178/178-degree viewing angles while maintaining consistent image quality and colors from all viewing positions.
Technical Specifications:
| Model name |
24B36H |
| Panel |
23.8" / IPS |
| Pixel Pitch (mm) |
0.2745 (H) × 0.2745 (V) |
| Effective Viewing Area (mm) |
527.04 (H) × 296.46 (V) |
| Brightness (typical) |
250 cd/m² |
| Contrast Ratio |
1500 : 1 (typical) / Mega DCR |
| Response Time |
4ms GtG / 1ms MPRT |
| Viewing Angle |
178° (H) / 178° (V) (CR > 10) |
| Color Gamut |
NTSC 91% (CIE1976) / sRGB 105% (CIE1931) |
| Color Accuracy |
- |
| Optimum Resolution |
1920 × 1080 @ 100Hz – HDMI; 1920 × 1080 @ 75Hz – VGA |
| Display Colors |
16.7 Million |
| Signal Input |
VGA × 1, HDMI 1.4 × 1 |
| HDCP Version |
- |
| USB Hub |
No |
| Power Supply |
External 19VDC, 1.31A |
| Power Consumption (typical) |
17W |
| Speakers |
No |
| Line in & Earphone |
Earphone |
| Wall-Mount |
100mm × 100mm |
| Adjustable Stand |
Tilt: -5° ~ 23° |
| Product without Stand (mm) |
316.2 (H) × 542.4 (W) × 34.7 (D) |
| Product with Stand (mm) |
410.0 (H) × 542.4 (W) × 198.0 (D) |
| Packaging (mm) |
381 (H) × 612 (W) × 93 (D) |
| Product without Stand (kg) |
2.15 |
| Product with Stand (kg) |
2.4 |
| Product with Packaging (kg) |
4.02 |
| Cabinet Color |
Black |
| Regulatory Approvals |
CE / FCC |
|
