Description
24B36H3
23.8" 120Hz IPS Monitor
Model Name | 24B36H3 |
---|---|
Panel | 23.8" / IPS LCD |
Pixel Pitch (mm) | 0.2745(H) * 0.2745(V) |
Effective Viewing Area (mm) | 527.04(H) * 296.46(V) |
Brightness (typical) | 300 cd/m² |
Contrast Ratio | 1500:1 (typical) / MEGA DCR |
Response Time | 4ms GtG / 1ms MPRT |
Viewing Angle | 178° (H) / 178° (V) (CR > 10) |
Color Gamut | NTSC 101% (CIE1976) / sRGB 116% (CIE1931) |
Optimum Resolution | 1920 x 1080 @ 120Hz - HDMI 1920 x 1080 @ 75Hz - VGA |
Display Colors | 16.7 Million |
Signal Input | VGA x 1, HDMI 1.4 x 1 |
USB Hub | No |
Power Supply | External 19VDC, 1.31A |
Power Consumption (typical) | 17W |
Speakers | No |
Line In/Earphone | No |
Wall-Mount | 100 mm x 100 mm |
Adjustable Stand | Tilt: -5° - 23° |
Product without Stand (mm) | 316.2(H) * 542.4(W) * 34.7(D) |
Product with Stand (mm) | 410(H) * 542.4(W) * 198(D) |
Packaging (mm) | 420(H) * 615(W) * 111(D) |
Product without Stand (kg) | 2.15 |
Product with Stand (kg) | 2.45 |
Product with Packaging (kg) | 4.43 |
Cabinet Color | Black |
Regulatory Approvals | CE / FCC / RoHS |
