The 2200VA/1320W tower UPS has 6 total outlets, 4 of which are battery back up and surge protection, and 2 that are surge protection only. It has a surge energy rating of 1080 Joules. It features Automatic Voltage Regulation to correct voltage dips and surges to proper levels. It comes with PowerChute Serial Shutdown, an easy-to-use safe system shutdown software with power and energy management features.
Pure sine wave ouptut provides cleanest signal for active PFC servers and electronics
12 customizable RGB LEDs
Reactor circle visually alerts of remaining power, surges, dips, power outages, and building wiring faults
3 USB smart charging ports (Type A + C) to plug in your wireless gaming devices and mobile phone
Environmental performance of the product
Specification:
Overview
Lead time
Usually in Stock
Main
Main Input Voltage
230 V AC 1 phase
Other Input Voltage
230 V
Main Output Voltage
230 V 1 phase
Rated power in W
1320 W
Rated power in VA
2200 VA
Product or component type
Uninterruptible power supply (UPS)
Input Connection Type
C19/C21
output connection type
2 IEC 60320 C13
Cable length
1.5 m
Number of cables
1
Battery type
Lead-acid battery
Batteries & Runtime
Number of battery filled slots
1
Number of battery free slots
0
Battery recharge time
16 h
Number of battery replacement quantity
1
Battery voltage
24 V
Overcurrent protection
15 A
Battery charger power
12 W rated
Battery life
3…5 year(s)
General
Provided equipment
safety guide
product web sub-family
Gaming performance
Number preinstalled power module
0
Number of power module free slots
0
Redundant
No
Physical
Colour
White
Height
292.1 mm
Width
104.1 mm
Depth
408.9 mm
Net weight
12.24 kg
mounting support
Floor
Mounting preference
No preference
mounting mode
Not rack-mountable
Two post mountable
0
USB compatible
Yes
mounting position
Vertical
Input
Network frequency
50/60 Hz +/- 3 Hz
Plug standard
C19/C21
Input voltage limits
168...302 V
Maximum input current
12 A
Switching current capacity
15 A
Input harmonic distortion
Less than 3 % for full load
Input protection type
Circuit breaker
Output
Maximum configurable power in W
1320 W
Output frequency
50/60 Hz +/- 3 Hz sync to mains
UPS type
Line interactive
Wave type
Sine wave
Full load runtime
00:30:00
Half load runtime
00:05:30
Maximum configurable power in VA
2200 VA
Transfer time
8 ms typical : 10 ms maximum
Conformance
Product certifications
CE
Equipment protection policy
Lifetime : $150000
Environmental
Ambient air temperature for operation
0…40 °C
Relative humidity
0…95 %
Operating altitude
0...10000 ft
Ambient air temperature for storage
-15…40 °C
Storage Relative Humidity
0…95 %
Storage altitude
0.0000000000…3048.0000000000 m
acoustic level
45 dBA
IP degree of protection
IP20
Communications & Management
Free slots
0
Control panel
Multifunction LCD status and control console
Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rate
1080 J
Noise suppression
Full time multi-pole noise filtering : 5% of IEEE surge let-through : zero clamping response time: instantaneous
