Description
FEATURES
- Cold-start capable - Provides temporary battery power when the utility power is out.
- Boost Automatic Voltage Regulation (AVR) - Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.
- Transformer-block spaced outlets - Protect equipment with input transformer blocks without blocking access to other receptacles.
- Sleek design - Slim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home décor.
PROTECTION
- Battery backup and surge protection - Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.
- Battery and surge protected outlets - Back up and protect your hardware and data during power outages, surges and spikes.
MANAGEABILITY
- LED Indicators - Provide easy-to-read status of the unit and utility power conditions.
- Audible alarms - Provides notification of changing utility power and UPS power conditions
SPECIFICATIONS
OUTPUT |
|
| MAX CONFIGURABLE POWER (Watts) | 650 Watts / 1.2kVA |
| OUTPUT FREQUENCY (Sync to mains) | 50/60 Hz +/- 1 Hz Sync to mains |
| TOPOLOGY | Line interactive |
| WAVEFORM TYPE | Stepped approximation to a sinewave |
| TRANSFER TIME | 6 ms typical : 10 ms maximum |
INPUT |
|
| INPUT FREQUENCY | 50/60 Hz +/- 5 Hz Auto-sensing |
| INPUT VOLTAGE RANGE FOR MAIN OPERATIONS | 140 – 300 (230 V) ACV |
| NUMBER OF POWER CORDS | 1 |
| INPUT POWER FACTOR AT FULL LOAD | 0.51 |
BATTERIES & RUNTIME |
|
| BATTERY TYPE | Lead-acid battery |
| TYPICAL RECHARGE TIME | 8 hour(s) |
| NOMINAL BATTERY VOLTAGE | 12 V |
| EXPECTED BATTERY LIFE | 1 – 2 |
| BATTERY VOLT-AMP-HOUR CAPACITY | 108 |
COMMUNICATIONS & MANAGEMENT |
|
| CONTROL PANEL | LED Status display with on line : on battery |
| AUDIBLE ALARM | Alarm when on battery : distinctive low battery alarm |
SURGE PROTECTION AND FILTERING |
|
| SURGE ENERGY RATING | 273Joules |
PHYSICAL |
|
| MAXIMUM HEIGHT | 190MM, 19.0CM |
| MAXIMUM WIDTH | 140MM, 14.0CM |
| MAXIMUM DEPTH | 390MM, 39.0CM |
