| Technical Specifications & Manual |
| General Specifications |
| TIM |
MX-6 (0.8 g) |
| Warranty |
6 Years |
| Operating Ambient Temperature |
0—40 °C |
| Pump |
800–2800 rpm (PWM controlled) |
| Current | Voltage |
0.35 A | 12 V DC |
| Cold Plate |
Copper, Micro Skived Fins |
| Tube Length |
500 mm |
| Tube Diameter |
Outer: 12.4 mm / Inner: 6.0 mm |
| Weight |
2370 g |
| Compatibility |
| Intel |
LGA1851, LGA1700 |
| AMD |
AM5, AM4 |
| PI | NNPI |
420 | 376 |
| Radiator |
| Material |
Aluminium |
| Dimensions |
458 (L) x 138 (W) x 38 (H) mm |
| VRM Module |
| VRM Fan |
400–2500 rpm (PWM-controlled) |
| Current | Voltage |
0.05 A | 12 V DC |
| Radiator Fan |
| General |
3x P14 Pro |
| Speed |
400–2500 rpm |
| Airflow |
110 cfm | 186 m³/h |
| Static Pressure |
5.2 mmH2O |
| Bearing |
Fluid Dynamic Bearing |
| Current | Voltage |
0.35 A | 12 V DC |
| Connector |
4-Pin Fan Plug |
