Description
The Arctic TP-4 Premium Performance Thermal Pad (ACTPD00064A) is designed to support efficient heat transfer between electronic components and their cooling surfaces. With a 100 x 100 mm size and 1.5 mm thickness, this thermal pad is suitable for applications that require a thicker thermal interface to bridge gaps between compatible components and heatsinks.
Engineered for a wide operating temperature range of -40°C to 200°C, the Arctic TP-4 provides dependable performance under varying thermal conditions. Its soft 50 Shore OO hardness allows it to conform to surface irregularities, helping maintain effective contact for consistent heat dissipation. The pad also offers electrical insulation properties and a UL 94 V-0 flammability rating.
Specification:
| General Specifications | |
|---|---|
| Operating Ambient Temperature | -40-200 °C |
| Dimensions | 100 (L) x 100 (W) x 1.5(H) mm |
| Thermal Pad Specifications | |
| Hardness | 50 Shore OO |
| Specific Gravity | 3.4 g/cm³ |
| Breakdown Voltage | 8620 V/mil |
| Dielectric Constant | 7.2 @1 MHz |
| Volume Resistance | 1.52 x 1013 Ω-cm |
| Flammability Rating | UL 94 V-0 |
| Packaging | |
| Width | 115 mm |
| Height | 2.5 mm |
| Length | 120 mm |
| Weight | 0.054 kg |
