Description
AMD Radeon™ RX 7900 XTX Taichi White 24GB OC
-
Clock: GPU / Memory
Boost Clock**: Up to 2680 MHz / 20 Gbps
Game Clock*: 2510 MHz / 20 Gbps -
Key Specifications
AMD Radeon™ RX 7900 XTX GPU
24GB GDDR6 on 384-Bit Memory Bus
96 AMD RDNA™ 3 Compute Units (With RT+AI Accelerators)
96MB AMD Infinity Cache™ Technology
PCI® Express 4.0 Support
3 x 8-pin Power Connectors
3 x DisplayPort™ 2.1 / 1 x HDMI™ 2.1 -
Key Features
Polychrome SYNC
Taichi 3X Cooling System
ARGB Backplate
Reinforced Metal Frame
Dual BIOS
22 Power Phase Design
110/100/110mm Striped Ring Fans
SPECIFICATION
| Graphics Engine | AMD Radeon™ RX 7900 XTX |
| Bus Standard | PCI® Express 4.0 x16 |
| DirectX | 12 Ultimate |
| OpenGL | 4.6 |
| Memory | 24GB GDDR6 |
| Engine Clock | Boost Clock*: Up to 2680 MHz |
| Game Clock**: 2510 MHz | |
| *Boost Clock is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads. **Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary. |
|
| Stream Processors | 6144 |
| Compute Units | 96 |
| Memory Clock | 20 Gbps |
| Memory Interface | 384-bit |
| Resolution | Digital Max Resolution: 7680x4320 |
| Interface | 3 x DisplayPort™ 2.1* 1 x HDMI™ 2.1 *DisplayPort (DP) 2.1 on any one or two ports. DisplayPort (DP) 1.4a on any and up to 3 ports simultaneously. |
| HDCP | Yes |
| Multi-view | 4 |
| Recommended PSU | 1000W |
| Power Connector | 3 x 8-pin |
| Accessories | 1 x Quick Installation Guide 1 x Taichi White Post Card 1 x Graphics Card Stand |
| Dimensions | 345 x 140 x 61 mm, 3-slot |
