Description
ROG Exclusive Animation
Ten exclusive ROG animations are available for you to cast through the Matrix screen. Select your favorite and customize the sequence or use the Pixel Editor to create your own!
System Monitoring
Install Armory Crate and display your choice of system temperatures, voltages, and fan speeds from the beating heart of your rig.
Aura Sync
Customize the color and effects displayed on the ARGB fans and AniMe Matrix screen, and then synchronize with a vast range of Aura compatible system components to create a unified theme throughout your build
Pixel Editor
Create your own images and text using the Armory Crate Pixel Editor, then upload to add a dash of unique personality to your rig
Water Block
Water block dimention:89 x 89 x 68.3 mm
Block Material (CPU Plate):Copper
Pump
Pump Solution:8th gen Asetek pump
Motor Speed:800 - 2,600 +/- 300 RPM
Radiator
Radiator Dimension: 279.5 x 120 x 30 mm
Radiator Material: Aluminum
Tube: Sleeved Rubber tube
Tube Length: 400 mm
Fan
Fan:ROG FAN MODEL 12 ARGB
- Size: 2 x Fan Slots (120mm)
- Dimension:120 x 120 x 25 mm
- Speed: 2200 +/- 300 RPM
- Static Pressure:3.88 mmH2O
- Air Flow: 70.07 CFM
- Noise: 36.45 dB(A)
- Control Mode: PWM/ DC
Special Features
Display:Anime Matrix LED
AURA Sync Support:Yes
Compatibility
Water Block
Water block dimention:89 x 89 x 68.3 mm
Block Material (CPU Plate):Copper
Pump
Pump Solution:8th gen Asetek pump
Motor Speed:800 - 2,600 +/- 300 RPM
Radiator
Radiator Dimension: 399.5 x 120 x 30 mm
Radiator Material: Aluminum
Tube: Sleeved Rubber tube
Tube Length: 400 mm
Fan
Fan:ROG FAN MODEL 12 ARGB
- Size: 3 x Fan Slots (120mm)
- Dimension:120 x 120 x 25 mm
- Speed: 2200 +/- 300 RPM
- Static Pressure:3.88 mmH2O
- Air Flow: 70.07 CFM
- Noise: 36.45 dB(A)
- Control Mode: PWM/ DC
Special Features
Display:Anime Matrix LED
AURA Sync Support:Yes
Compatibility
Intel: LGA 1700, 1200, 115x
AMD: AM5,AM4
