Description
MUX switch
Modern gaming laptops use powerful, dedicated graphics chips for high performance—but most route those frames through the CPU's integrated graphics before reaching the display. This offers better battery life, but prevents your GPU from giving its absolute best performance. So we're bringing a MUX switch to all 2022 ROG laptops. For competitive games, you can switch to a direct GPU mode that reduces latency and boosts performance by an average of 9%.
SPECIFICATIONS:
- PROCESSOR: Intel® Core™ i9-12900H
- DISPLAY: 16" QHD (2560 x 1600)
- MEMORY: 16GB DDR5 on board
- STORAGE: 1TB PCIe® 4.0 NVMe™ M.2 SSD
- GPU: NVIDIA® GeForce RTX™ 3050 Ti
- OS: Windows 11 Home
- COLOR: Off Black
FULL SPECIFICATION
| Marketing Name | ROG Zephyrus M16 |
| Color | Off Black |
| Dimension (W x D x H) | 35.5 x 24.3 x 1.99 ~ 1.99 cm |
| Weight | 2.00 Kg |
| Processor | 12th Gen Intel® Core™ i9-12900H Processor 2.5 GHz (24M Cache, up to 5.0 GHz, 14 cores: 6 P-cores and 8 E-cores) |
| Chipset | TBD |
| Discrete/Optimus | MUX Switch + Optimus |
| Graphic | NVIDIA® GeForce RTX™ 3050 Ti Laptop GPU |
| Graphic Wattage | ROG Boost: 1745MHz* at 100W (1695MHz Boost Clock+50MHz OC, 80W+20W Dynamic Boost) |
| Graphic Memory | 4GB GDDR6 |
| IGPU | Intel® UHD Graphics 630 |
| Panel Size | 16-inch |
| Resolution | QHD+ 16:10 (2560 x 1600, WQXGA) |
| Refresh Rate | 165Hz |
| Response Time (G2G) | 3ms |
| Viewing Angle | 85/85/85/85 |
| Panel Tech | IPS-level |
| Brightness | 500nits |
| Contrast | 1200:1 |
| DCI-P3 % | 100% |
| Anti glare | anti-glare display |
| Adaptive-Sync technology | Adaptive-Sync |
| Pantone | Pantone Validated |
| Nebula Display | ROG Nebula Display |
| Support Dolby Vision HDR | Yes |
| Total System Memory | 8GB DDR5 on board + 8GB DDR5-4800 SO-DIMM |
| On board memory | 8GB DDR5 on board |
| Memory Slot | 1x SO-DIMM slot |
| DIMM Memory | 8GB DDR5-4800 SO-DIMM |
| Memory Max. | 40GB |
| Multi-channel memory technology | Support dual channel memory |
| System Storage Installed | 1TB PCIe® 4.0 NVMe™ M.2 SSD |
| M.2 slots support either SATA or NVMe | 2 |
| M.2 SSD Support List | Value PCIe G4x4 SSD M2 2280 P4X4 512G SSD M2 2280 P4X4 1TB |
| How to upgrade memory | Upgradable |
| Expansion Slot (includes used) | 1x DDR5 SO-DIMM slot 1x PCIe |
| LAN | 10/100/1000/2500 Mbps |
| Wi-Fi/Bluetooth | Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth 5.2 (*BT version may change with OS upgrades.) |
| I/O Ports | 1x RJ45 LAN port 1x Thunderbolt™ 4 support DisplayPort™ / power delivery 1x USB 3.2 Gen 2 Type-C support DisplayPort™ / power delivery 2x USB 3.2 Gen 2 Type-A 1x card reader (microSD) (UHS-II, 312MB/s) |
| Display output | 1x HDMI 2.0b |
| Audio | 1x 3.5mm Combo Audio Jack |
| Webcam | 720P HD IR Camera for Windows Hello |
| Mic | Built-in array microphone |
| Keyboard Type | Backlit Chiclet Keyboard 1-Zone RGB |
| NumberPad | N/A |
| Aura Sync | N/A |
| Speakers | 2x 2W dual-force woofer with Smart Amp Technology 2x 2W Tweeter |
| Audio Tech | AI noise-canceling technology Dolby Atmos Hi-Res certification Smart Amp Technology |
| Operating System | Windows 11 Home |
