Description
- New-Gen WiFi Standard – Supporting 802.11ax WiFi standard for better efficiency and throughput.
- Ultra-fast WiFi Speed – RT-AX52 supports 1024-QAM for dramatically faster wireless connections. With a total networking speed of about 1800Mbps — 574 Mbps on the 2.4GHz band and 1201 Mbps on the 5GHz band.
- Increase Capacity and Efficiency – Supporting not only MU-MIMO but also OFDMA technique to efficiently allocate channels, communicating with multiple devices simultaneously
- Easy Extendable Network – Enjoy seamless roaming with rich, advanced features by adding any AiMesh-compatible router.
SPECIFICATIONS
| Model | RT-AX52 |
| Network Standard | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) IPv4 IPv6 |
| Product Segment |
AX1800 ultimate AX performance : 1201 Mbps+ 574 Mbps
|
| WiFi Data Rate | 802.11a : up to 54 Mbps 802.11b : up to 11 Mbps 802.11g : up to 54 Mbps WiFi 4 (802.11n) : up to 300 Mbps WiFi 5 (802.11ac) : up to 867 Mbps WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps |
| Antenna | Internal Antenna x 4 |
| Transmit / Receive | 2.4GHz 2x2 5GHz 2x2 |
| Processor | 1.3GHz dual-core processor |
| Memory | 128 MB Flash 256 MB RAM |
| Operating Frequency | 2.4GHz / 5GHz |
| I/O Ports |
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 3
|
| Buttons | WPS Button, Reset Button, Power Switch |
| LED Indicator | Power x 1 WAN x 1 LAN x 3 2.4G x 1 5G x 1 WPS x 1 |
| Power Supply | AC Input : 110V~240V(50~60Hz) DC Output : 12 V with max. 1 A current |
| Product Dimensions | 192 x 126.3 x 47.5 mm (WxDxH) |
| Parental Control |
"Allow you to block access to unwanted websites and apps."
Customized Internet Schedule |
| Security |
Open system, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise
WPS SSH Firewall |
| WAN |
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
Dual WAN Port triggering DMZ DDNS |
| LAN | DHCP Server IGMP Snooping IPTV Manually Assign IP Address Wake on LAN (WOL) |
| Wireless | UTF-8 SSID WiFi MAC Address Filter Wireless Scheduler Airtime Fairness RADIUS Client Universal Beamforming Explicit Beamforming |
| VPN | Instant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Server IPSec VPN Server Open VPN VPN Server PPTP |
