ASUS TUF Gaming A16 FA608UM-RV115W Laptop (Jaeger Gray) | 16" FHD+ (1920x1200) 165Hz IPS | Ryzen 7 260 | 16GB RAM | 512GB SSD | RTX 5060 | Windows 11 Home + ASUS VP4700 Backpack
Description
Specifications:
| Model | FA608UM / 90NR0KV1-M00EW0 |
| Marketing Name | ASUS TUF Gaming A16 |
| Operating System | Windows 11 Home |
| Office | 1-month trial for new Microsoft 365 customers. Credit card required. |
| Color | Jaeger Gray |
| Dimension (W x D x H) | 35.4 x 26.9 x 1.79 ~ 2.57 cm (13.94" x 10.59" x 0.70" ~ 1.01") |
| Weight | 2.20 Kg (4.85 lbs) |
| Processor | AMD Ryzen™ 7 260 Processor 3.8GHz (24MB Cache, up to 5.1 GHz, 8 cores, 16 Threads); AMD XDNA™ NPU up to 16TOPS |
| Chipset | N/A |
| Intergrated GPU | AMD Radeon™ 780M Graphics |
| Discrete/Optimus | MUX Switch + NVIDIA® Advanced Optimus |
| Graphic | NVIDIA® GeForce RTX™ 5060 Laptop GPU |
| Graphic Wattage | 1737 MHz* at 55W (1687 MHz Boost Clock+50MHz OC, up to 115W Dynamic Boost) |
| Graphic Memory | 8GB GDDR7 |
| Neural Processor | AMD XDNA™ NPU up to 16TOPS |
| Panel Size | 16-inch |
| Resolution | FHD+ 16:10 (1920 x 1200, WUXGA) |
| Refresh Rate | 165Hz |
| Response Time (G2G) | 3ms |
| Viewing Angle | 85/85/85/85 |
| Panel Tech | IPS-level |
| Brightness | 300 nits |
| Contrast Ratio | 1000:1 |
| NTSC % | 72.00% |
| SRGB % | 100% |
| Adobe % | 75.35% |
| Surface texture of display | Anti-glare(AG) display |
| Adaptive-Sync technology | G-Sync |
| Pantone | N/A |
| Support Dolby Vision HDR | N/A |
| On board memory | N/A |
| DIMM Memory | 16GB DDR5-5600 SO-DIMM, the memory speed of the systems vary by CPU SPEC |
| Total System Memory | DDR5 16GB |
| Memory Slot | 2x SO-DIMM slots |
| Memory Max. | 64GB |
| How to upgrade memory | Upgradable |
| Storage | 512GB PCIe® 4.0 NVMe™ M.2 SSD |
| M.2 slots support either SATA or NVMe | 2 |
| M.2 SSD Support List | M.2 PCIe 512mb, M.2 PCIe 1TB, M.2 PCIe 2TB |
| Expansion Slot (includes used) | 2x DDR5 SO-DIMM slots, 2x M.2 PCIe |
| LAN | 10/100/1000 Mbps |
| Wireless | Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.4 Wireless Card (*Bluetooth® version may change with OS version different.) |
| I/O Ports | 1x RJ45 LAN port, 1x USB 2.0 Type-A, 1x USB 3.2 Gen 2 Type-C with support for DisplayPort™ / power delivery / G-SYNC, 2x USB 3.2 Gen 2 Type-A, 1x Type-C USB 4 with support for DisplayPort™ |
| Display output | 1x HDMI 2.1 FRL |
| Camera | 1080P FHD IR Camera for Windows Hello |
| Mic | Built-in array microphone |
| Keyboard Type | Backlit Chiclet Keyboard 1-Zone RGB, With Copilot key |
| Aura Sync | Yes |
| Touchpad | Touchpad |
| Speakers | 2-speaker system |
| Audio | 1x 3.5mm Combo Audio Jack, Built-in array microphone, AI noise-canceling technology, Dolby Atmos, Hi-Res certification |
| Security | BIOS Administrator Password and User Password Protection, Pluton Security Processor, Secured-core PC (Level 3) |
| Antivirus | McAfee® 30 days free trial |
| Battery | 90WHrs, 4S1P, 4-cell Li-ion |
| Fast charging | Recharge from 0-50% in 30 minutes |
| Power | Rectangle Conn, 240W AC Adapter, Output: 20V DC, 12A, 240W, Input: 100~240C AC 50/60Hz universal |
| Required charging power | Min: 45W, Max: 100W |
| Xbox Game Pass | Xbox Game Pass for PC_3 months |
| Ecolabels & Compliances | ENERGY STAR® |
| Reparability Index (for France) | 9.7 |
| Reparability Index (for BNL) | 9.8 |
