Description
SPECIFICATIONS:
- PROCESSOR: Intel Core i5-11400H
- DISPLAY: (15.6") 1920 x 1080
- MEMORY: 8 GB RAM
- STORAGE: 512 GB PCI Express
- GPU: GeForce® RTX™ 3050
- OS: Windows 11 Home
STAYING POWER
Geared for serious gaming and rocking a slick new style, TUF Gaming F15 is a feature-packed Windows 10 gaming laptop with the power to carry you to victory. The new GeForce RTX™ 3050 GPU delivers fluid gameplay on up to a 144Hz display with 100% sRGB, while the potent Up to Intel Core i7-11800H CPU is bolstered by improved cooling that amps CPU performance and keeps acoustics stealthy. A long-lasting 90Wh battery coupled with TUF’s military-grade durability keeps you on your best game anywhere.
DESIGN
STUN WITH STYLE
Personalize your experience with sleek Eclipse Gray or bold Graphite Black color options. A textured honeycomb design on the base adds grip and echoes the hexagon reinforcements around the chassis. Hairline brush strokes accent the palm area, adding a subtle texture that looks professional and clean.
Honeycomb Grip
Textured honeycomb grip coats the bottom of the chassis. Strategic cuts double as cooling vents.
Smart and Striking
Bold Graphite Black and sleek Eclipse Gray tints show off your personality.
Brushed Metal Finish
Contrasting hairline brushstrokes across the chassis are clean-cut and sleek.
VISUALS
SPEED TO VICTORY
Game at pro-speed with a fast, 100% sRGB IPS-level panel up to 144Hz. With Adaptive-Sync, the display’s refresh rate synchronizes with the GPU’s frame rate to reduce lag, minimize stuttering, and eliminate visual tearing for ultra-smooth and immersive gameplay. Ultrafast Thunderbolt™ 4 lets you connect conveniently on the fly, like powerful external GPUs or external monitors that level up your multitasking power. Play 4K Ultra HD movies, videos, and games on big-screen TVs with HDMI 2.0b.
*Thunderbolt 4 not supported on FX506HCB/HEB.
AUDIO
CRYSTAL CLEAR AUDIO
Two speakers with four cut-outs are loud and powerful, enabling deeper audio immersion. DTS:X™ Ultra delivers high-fidelity audio for clear, precise sound. Virtual 7.1-channel surround sound enhances spatial awareness in-game to help you get the drop on enemies. Up to 8 preset modes for music, movies, and gaming genres optimize your experience further, on top of the built-in equalizer that lets you fine-tune your settings at will.
THERMAL
LASTING COOL
Comprehensive cooling sustains long-term system reliability and extends the lifespan of your machine. Four heatpipes and three heatsinks draw heat away from your hardware and dissipates it quickly, keeping component temperatures at optimum levels. A self-cleaning cooling design ensures that your cooling system stays debris-free for full functionality for the long haul. Tuned operating modes balance clock speeds and acoustics for the task at hand, customizable to your needs.
| Part No | 90NR0724-M00XX0 |
| Model Name | FX506HC-HN111W |
| EAN Code | 4711387286210 |
| UPC Code | 197105286214 |
| Marketing Name | ASUS TUF Gaming F15 |
| Color | Graphite Black |
| Dimension (W x D x H) | 35.9 x 25.6 x 2.28 ~ 2.45 cm (14.13" x 10.08" x 0.90" ~ 0.96") |
| Weight | 2.30 Kg ( lbs) |
| Processor | Intel® Core™ i5-11400H Processor 2.7 GHz (12M Cache, up to 4.5 GHz, 6 Cores) |
| Chipset | Mobile Intel® HM570 Express Chipsets |
| Discrete/Optimus | Optimus |
| Graphic | NVIDIA® GeForce RTX™ 3050 Laptop GPU |
| Graphic Wattage | Up to 1600MHz at 60W (75W with Dynamic Boost) |
| Graphic Memory | 4GB GDDR6 |
| IGPU | Intel® UHD Graphics |
| Panel Size | 15.6-inch |
| Resolution | FHD (1920 x 1080) 16:9 |
| Refresh Rate | 144Hz |
| Viewing Angle | 85/85/85/85 |
| Panel Tech | Value IPS-level |
| Brightness | 250 |
| Contrast | 1000:1 |
| NTSC % | 45% |
| SRGB % | 62.5% |
| Adobe % | 47.34% |
| DCI-P3 % | N/A |
| Anti glare | Anti-glare display |
| Adaptive-Sync technology | Adaptive-Sync |
| Pantone | N/A |
| Support Dolby Vision HDR | N/A |
| On board memory | N/A |
| DIMM Memory | 8GB DDR4-3200 SO-DIMM |
| Total System Memory | DDR4 8GB |
| Memory Slot | 2x SO-DIMM slots |
| Memory Max. | 32GB |
| How to upgrade memory | Upgradable |
| System Storage Installed | 512GB PCIe® 3.0 NVMe™ M.2 SSD |
| M.2 slots support either SATA or NVMe | 2 |
| M.2 SSD Support List | M.2 512GB G3x4 PCIe SSD M.2 1TB G3x4 PCIe SSD |
| Expansion Slot (includes used) | 2x DDR4 SO-DIMM slots 2x PCIe |
| LAN | 10/100/1000 Mbps |
| Wi-Fi/Bluetooth | Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth® 5.3 Wireless Card (*Bluetooth® version may change with OS version different.) |
| I/O Ports | 1x RJ45 LAN port 3x USB 3.2 Gen 1 Type-A 1x Thunderbolt™ 4 support DisplayPort™ |
| Display output | 1x HDMI 2.0b |
| Audio | 1x 3.5mm Combo Audio Jack |
| Webcam | 720P HD camera |
| Mic | Built-in array microphone |
| Keyboard Type | Backlit Chiclet Keyboard 1-Zone RGB |
| NumberPad | N/A |
| Aura Sync | N/A |
| Speakers | 2-speaker system |
| Audio Tech | AI noise-canceling technology DTS software Support Microsoft Cortana near field/Far field |
| Operating System | Windows 11 Home |
| Office | 1-month trial for new Microsoft 365 customers. Credit card required. |
| Xbox Game Pass | Xbox Game Pass for PC_1 month (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass for PC. Eligible markets are determined at activation. Game catalog varies by region, device, and time.) |
| Security | BIOS Administrator Password and User Password Protection Kensington Security Slot™ Trusted Platform Module (Firmware TPM) |
| Battery | 48WHrs, 3S1P, 3-cell Li-ion |
| Fast charging | Recharge from 0-50% in 30 minutes |
| Power | ø6.0, 180W AC Adapter, Output: 20V DC, 9A, 180W, Input: 100~240V AC, 50/60Hz universal |
| Reparability Index (for FR) | 6.3 |
