Description
- Capture astonishing 4Kp60 HDR video content
- Record up to 240 frames per second in crystal clear full HD
- Uncompressed videos ensure that your gameplay is completely unaltered
- High Refresh Rate passthrough get an edge over the competition with support for 144hz and 240hz displays
- Play right on the RECentral preview window with virtually no latency
- Powered by Intel Thunderbolt 3 and works with both MacOS 10.15 or greater and Windows 10
- Not compatible with USB-C, a Thunderbolt 3 port is required for operation
Specifications
- Interface: Thunderbolt 3*
- Input & Output (Pass-Through): HDMI 2.0
-
Max. Pass-Through Resolution :
2160p60 HDR /1440p144/ 1080p240 -
Max. Recording Resolution:
2160p60 HDR* /1440p144/ 1080p240 -
Supported Resolution:
2160p, 1440p, 1080p, 1080i, 720p, 576p, 480p - Record Format: MPEG 4**
-
Dimensions (W x D x H):
120 x 120 x 29.3 mm (4.72 x 4.72 x 1.15 in) - Weight :348 g (12.27 oz)
*LGB does not support USB 2.0, 3.0, 3.1, 3.2. You need to connect it to a ThunderboltTM 3 port
**H.264 & H.265 encoder is provided by GPU; Audio codec is provided by OS
- LGB Supports 7.1/5.1 Ch. LPCM surround sound pass-through
- LGB does not support viewing/recording/streaming of HDCP protected signals
System Requirements
- Operating system: Windows® 10 x64
Laptop
For 4Kp60 HDR or 1080p240 recording:
- Intel Core i7-7700HQ or above
- NVIDIA® GeForce® GTX1050 Ti or above
- 8 GB*
For 1080p60 recording: - Intel Core i7-4810MQ
- NVIDIA® GeForce® GTX 870M or above
- 8 GB
Desktop
For 4Kp60 HDR or 1080p240 recording:
- Intel® Core™ i5-6XXX / AMD Ryzen™ 3 XXX or above
- NVIDIA® GTX 1060 / AMD RX 5700 or above
- 8 GB*
For 1080p60 recording (4Kp60 HDR pass-through supported):
- Intel® Core™ i5-3330 or above (i7-3770 recommended)
- NVIDIA® GeForce® GTX 650 / AMD Radeon™ R7 250X or above
- 4 GB
* RAM must be DDR4 2400 or above
– The Live Gamer BOLT works with ThunderboltTM 3 PCIe expansion cards for desktops. Make sure to find a compatible expansion card for your specific motherboard.
– If you experience drop frames while using ThunderboltTM 3 expansion cards, disconnect other external devices.
– If you experience drop frames while using Thunderbotl 3 hub on a laptop, disconnect other external devices or connect the Live Gamer BOLT directly to the laptop's ThunderboltTM 3 port .
– The Live Gamer BOLT does not support energy saving CPUs.
– Make sure you Laptop and PC meet the system requirements aside from having a ThunderboltTM 3 port.
-
Mac system requirement :
Operating system: MacOS High Sierra 10.15 and above Mac Thunderbolt 3
For 4Kp60 or 1080p240 Recording (4Kp60 HDR pass-through supported)
iMac 2019:
- 3.2GHz 6-core Intel Core i7
- Radeon Pro 555X with 2GB of GDDR5 memory
- 16GB of 2400MHz DDR4 memory
MacBook Pro 2018:
- 2.6GHz 6-core Intel Core i7
- Radeon Pro 560X with 4GB of GDDR5 memory and above
- 16GB 2400MHz DDR4 memory
Notes:
1. HDR recording not supported on MAC.
2. Preset color space NV12.
3. Thunderbolt 3 cable and port required.
