Description
CyberPower BU1000EA provides home and office users with a reliable battery backup and safeguards office PCs and other electronic devices from surges, spikes, brownouts and other power irregularities. The product adopts line-interactive topology with Automatic Voltage Regulation (AVR) function to offer stabilized AC power output.
The patented GreenPower UPS™ Bypass design helps UPS achieve ultra-low power consumption to reduce energy costs while lowering UPS operating temperature, which extends its battery lifespan. Configurable alarm allows users to switch the audible alarm on or off during battery mode to avoid unnecessary disturbances. Its desktop design allows users to place it easily on desks or other tight spaces.
Specifications:
| General | |
|---|---|
| Phase | Single Phase |
| Form Factor | Desktop |
| UPS Topology | Line-interactive |
| Energy Saving Technology | GreenPower UPS™ Bypass Technology |
| Input | |
| Generator Compatibility | Yes |
| Nominal Input Voltage (Vac) | 230 ± 10% |
| Input Voltage Range (Vac) | 165 ~ 280 |
| Input Frequency (Hz) | 50 ± 5 / 60 ± 5 |
| Input Frequency Detection | Auto-sensing |
| Rated Input Current (A) | 4.55 |
| Input Connector Type | NEMA 5-15P |
| Power Cord Length (ft.) | 4 |
| Power Cord Length (m.) | 1.2 |
| Output | |
| Capacity (VA) | 1000 |
| Capacity (Watts) | 630 |
| On Battery Waveform | Simulated Sine Wave |
| On Battery Voltage(s) (Vac) | 230 ± 10% |
| On Battery Frequency (Hz) | 50 ± 1% / 60 ± 1% |
| Automatic Voltage Regulation (AVR) | Single Boost, Single Buck |
| Overload Protection | Circuit Breaker |
| Outlet(s) - Total | 4 |
| Outlet Type | AS x 4 |
| Outlet(s) - Battery & Surge Protected | 4 |
| Typical Transfer Time (ms) | 4 |
| Battery | |
| Runtime at 60W (min) | 74 |
| Runtime at 90W (min) | 45 |
| Typical Recharge Time (Hours) | 8 |
| Start On Battery | Yes |
| User-replaceable | No |
| Battery Type | Sealed Lead-acid |
| Surge Protection & Filtering | |
| Surge Suppression (Joules) | 150 |
| EMI/RFI Filtration | Yes |
| Management & Communications | |
| LED Indicators | Power On, Line Mode, Battery Mode, Low Battery |
| Audible Alarms | Battery Mode, Low Battery, Overload, UPS Fault |
| Physical | |
| Enclosure Construction | Plastic |
| Color | Black |
| Physical Size - UPS Module (in.) | 7.48 x 4.35 x 11.42 |
| Physical Size - UPS Module (mm.) | 190 x 110.5 x 290 |
| Weight (kg.) | 7.0 |
| Shipping Dimensions | |
| Dimensions (in.) | 6.3 x 10.4 x 13.3 |
| Dimensions (mm.) | 161 x 265 x 338 |
| Weight (lbs.) | 15.64 |
| Weight (kg.) | 7.11 |
| Environmental | |
| Operating Temperature (°F) | 32 ~ 104 |
| Operating Temperature (°C) | 0 ~ 40 |
| Operating Relative Humidity ( % ) | 0 ~ 90 (Non-condensing) |
| Operating Elevation | 0-9,843 feet (0-3,000 meters) |
| Storage Temperature (°F) | -4 ~ 122 |
| Storage Temperature (°C) | -20 ~ 50 |
| Storage Relative Humidity ( % ) | 0 ~ 90 (Non-condensing) |
| Storage Elevation | 0-9,843 feet (0-3,000 meters) |
| Online Thermal Dissipation (BTU/hr) | 45 |
| Audible Noise at 1.5M (dBA) | 40 |
| Certifications | |
| RoHS | Yes |
