Description
COMPACT 750W POWER FOR HIGH-PERFORMANCE SFF BUILDS
Deliver reliable, efficient power in a compact package with this 750W SFX Power Supply, designed for modern small form factor systems. Supporting SFX12V V4.1 and ATX12V V3.1, it combines a compact 125mm chassis, Cybenetics Platinum efficiency certification, and a robust power platform suited for space-conscious gaming and enthusiast PC builds.
HIGH EFFICIENCY & STABLE POWER
The power supply features an Active PFC + Half Bridge SRC LLC + DC to DC topology and full Japanese electrolytic capacitors for dependable power delivery. With Cybenetics Platinum / PPLP Gold certification and efficiency of ≥90% under typical 50% loading, it is designed to deliver efficient operation across everyday workloads.
COMPACT SFX FORM FACTOR
Measuring just 125 × 100 × 63.5mm, the compact SFX design makes it an excellent fit for space-constrained PC configurations. Its 92mm Fluid Dynamic Bearing (FDB) fan provides cooling while maintaining a practical compact footprint.
COMPREHENSIVE PROTECTION
Multiple built-in protection systems help safeguard the power supply and connected components, including Over Power Protection, Over Voltage Protection, Short Circuit Protection, Over Temperature Protection, Over Current Protection, Under Voltage Protection, Surge and Inrush Protection, and No Load Operation.
BUILT FOR LONG-TERM RELIABILITY
With a 100,000-hour MTBF, a ≥16ms hold-up time at 80% load, and a 5-year warranty, this 750W SFX power supply is designed to provide dependable operation for compact gaming PCs, workstations, and enthusiast builds.
Specifications:
| Total Output | 750W |
| Type | SFX12V V4.1 & ATX12V V3.1 |
| Product Dimensions | 125×100×63.5mm(WxLxH) |
| Efficiency certification | Cybenetics Platinum /PPLP Gold |
| Fan Size | 92×92×20mm(WxLxH) |
| Fan Bearing | FDB (Fluid Dynamic Bearing) |
| Topology | Active PFC + Half Bridge SRC LLC + DC to DC |
| Capacitors | Full Japanese Electrolytic Capacitors |
| Power Good Signal | 100-150ms |
| Hold Up Time | ≥16ms(80% Load) |
| Efficiency | ≥90% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
| Operation Temperature | 0~40C |
| Regulatory | CE/CCC/TUV-RH/KC/RCM/CAN ICES(B)/NMB(B)/EAC |
| Erp Regulation | ErP 2014 |
| Environment Protection | WEEE/ RoHS/Triman/EAC RoHS |
| MTBF | 100,000 Hours |
| Warranty | 5Years |
