Description
| Specification | Details |
|---|---|
| Model | GP-P650G PG5 |
| Type | Intel Form Factor ATX 12V v3.1 |
| PFC | Active PFC (>0.9 typical) |
| Input Voltage | 100–240 Vac |
| Input Current | 10–6A |
| Input Frequency | 50–60 Hz |
| Output Capacity | 650W |
| Efficiency Certification | 80 PLUS Gold |
| Efficiency | 90% at typical load |
| Fan Type | 120mm HYB Fan |
| Dimensions (L×W×H) | 150 × 140 × 86 mm |
| MTBF | >100,000 hours |
| Protections | OVP / OPP / SCP / UVP / OCP / OTP |
| Power Good Signal | 100–150 ms |
| Hold Up Time | >17 ms |
| Cable Type | Embossed, all black |
| Connectors | ATX/MB 20+4 Pin: 1 × 600 mm CPU/EPS 4+4 Pin: 1 × (600 mm + 150 mm) PCI-e 16 Pin: 1 × 500 mm PCI-e 6+2 Pin: 2 × (500 mm + 150 mm) SATA: 6 × (420 mm + 150 mm + 150 mm ×2) 4 Pin Peripheral: 3 × (420 mm + 150 mm + 150 mm ×1) |
