| Basic Information |
| Product Positioning |
Handheld Game Console |
| Operating System |
Pre-installed with Windows 11 Home 64bit, with the option to install either Steam OS or GPD OS
|
| Display |
| Touch Panel |
Supports |
| Screen Type |
Corning Gorilla Glass 5，H-IPS Technology |
| Screen Size |
6 Inches, Native Landscape Mode, DC Dimming |
| Aspect Ratio |
16:09 |
| Screen Resolution |
1920 × 1080, 1280 × 720, Image resolution: 40Hz & 60Hz |
| Pixels Per Inch |
368 PPI |
| CPU |
| Product model |
AMD Ryzen 7 8840U |
| Architecture |
Zen 4（Hawk Point） |
| # of CPU Cores / # of Threads |
8C / 16T |
| Base Clock |
3.3 GHz |
| Max. Boost Clock |
5.1 GHz |
| AI Performance |
16 TOPS |
| Total Processor Performance |
38 TOPS |
| Total Cache |
24.5 MB |
| Process Size |
4nm |
| TDP |
15W-30W |
| GPU |
| Processor Graphics |
AMD Radeon 780M |
| Architecture |
RDNA 3.0 |
| Graphics Frequency |
2700 MHz |
| Compute Units |
12CU |
| Shading Units |
768 |
| Floating-point Performance |
17.82 TFlops (FP16) |
| 8.92 TFlops (FP32) |
| 556.8 GFlops (FP64) |
| Pixel Rate |
92.80 GPixel/s |
| Texture Rate |
139.2 GTexel/s |
| Video Memory |
The Default Shared Memory Is 3GB, With A Maximum Allocation Of 16GB, Which Requires Manual Adjustment In The BIOS |
| HDMI |
7680 x 4320 @60Hz |
| DP |
7680 x 4320 @60Hz |
| DirectX |
DX12 Ultimate |
| OpenGL |
4.6 |
| Storage |
| Memory |
32GB |
| Memory Types |
LPDDR5x 7500 MT/s |
| Memory Channel |
Quad 32-bit Channels |
| Hard Disk Type |
M.2 SSD |
| Hard Disk Interface |
Socket 3 |
| Hard Disk Specifications |
M.2 NVMe 2280 × 1 |
| Standard Capacity |
2TB M.2 NVMe 2280 SSD |
| Bus Specification |
PCIe 4.0 × 4 |
| Transfer Protocol |
NVMe 1.3 / 1.4 |
| Multimedia Support |
| Audio System |
Built-in Sound Chip + Intelligent Amplifier That Features High Energy Efficiency, High PSRR and Low Noise |
| Loudspeakers |
Built-in Dual Speakers |
| Microphone |
Built-in Microphone |
| Network Communications |
| 4G LTE Module |
Back-mount Module, Selectable |
| Type of SIM Card: Nano-SIM, Single |
| 4G Network：TD-LTE，FDD-LTE |
| 3G Network：WCDMA/TD-SCDMA/CDMA |
| 2G Network：GSM |
| Frequency Band： |
| LTE-FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28 |
| LTE-TDD: B38/B39/B40/B41 |
| UMTS: B1/B2/B4/B5/B6/B8/B9 |
| GSM: B2/B3/B5/B8 |
| Wi-Fi |
IEEE 802.11 a/b/g/n/ac/ax, Support 2.4G/5G Dual Frequency Band, Dual Channel Maximum Transmission Rate 2402Mbps |
| Bluetooth |
5.2 |
| I/O Interface |
| Video / Data / Charging |
USB4, 40Gbps (Full Speed) × 1 |
| USB 3.2 Gen 2 Type-C Full-featured, 10Gbps × 1 |
| USB 3.2 Gen 2 Type-C Charging Only (Provided By The Dock) × 1 |
| Oculink (SFF-8612) female port with a bandwidth of 63Gbps and a throughput of up to 7.877GB/s × 1 |
| USB 3.2 Gen 2 Type-A, 10Gbps (Provided By The Dock) × 3 |
| HDMI 2.0 (Provided By The Dock) × 1 |
| microSDXC Slot |
Bus interface: UHS-I |
| Speed Class: Class 10 |
| Ultra High Speed: U3 |
| Video Speed Class: V30 |
| Application Performance Class: A2 |
| Read/Write: 160MB/s, 90MB/s |
| Maximum Capacity: 2TB |
| Ethernet Interface |
RJ45 (Provided By The Dock) × 1 |
| Audio Port |
3.5mm Headphone/Microphone Combo Interface, Compatible With Apple Headphones (US Specification) × 1 |
| BIOS Reset Port |
Supports |
| I/O Device |
| Keyboard |
QWERTY Full Keyboard Design, Scissor-Switch Keys, White Backlight, And Combination Keys For On/Off Function |
| Mouse |
Mouse 1: Right Joystick Simulates Mouse, Requires Switching Between "Gamepad/Mouse" Mode |
| Mouse 2: Optical Finger Mouse With Support For Click Confirmation Via Pressure |
| Fingerprint Recognition |
Yes |
| Joystick |
ALPS OEM Dual 3D Joysticks With Native Support For L3/R3 Via Downward Press |
| D-Pad |
Siamese Cross Key |
| Game Function Buttons |
ABXY、△○×□ Double Character Print, Select, Start, Xbox Controller Home |
| Game Accessories Buttons |
L1/R1 Feature Rainbow Lighting Design, While L2/R2 Are Linear Analog Buttons |
| Handle Vibration |
Dual Vibration Motors, Software Controlled, Capable Of: Turning Off, Weak Vibration, Strong Vibration |
| Dorsal Key |
Two Back Buttons, Mappable And Programmable |
| Other Keys |
Volume +/- Buttons, Power Button, Gamepad/Mouse Mode Switch |
| Sensor |
6-axis Design: 3-axis G-sensor, 3-axis Gyro |
| Speaker |
2 Pcs |
| Indicator Lamp |
Charging Indicator, Running Indicator |
| Battery |
| Battery Type |
Li-polymer |
| Battery Capacity |
45.62Wh |
| Battery Life |
Up to 2 Hours Of Heavy Use, Up to 3-6 Hours Of Moderate Use, Up to 10 Hours Of Light Use, Depending On The Specific Environment Of Use |
| Appearance |
| Net Weight |
598g |
| Length |
220×92×28mm |
| Shell Material |
LG-DOW 121H Aviation ABS, UL94-V0, Magnesium Alloy |
| Shell Color |
Black |
| Thermal Design |
Active Thermal Dissipation, Large Fan, Double Thick-walled Heat Pipes |
