Description
SPECIFICATION:
| Basic Information | |
| Product Name | WIN Max 2 (2024) |
| Launch Date | Mar-24 |
| Product Positioning | Handheld Game Laptop |
| Operating System | Pre-installed with Windows 11 Home 64bit, with the option to install either Steam OS 3.0 or GPD OS |
| Display | |
| Characteristic | Full Screen |
| Touch Panel | Support, 10-point Touch Control，Supported (Requires Separate Purchase), Active Pen With 4096-level Pressure Sensitivity, Original Handwriting, Compatible With Surface Pen |
| Screen Type | Corning Gorilla Glass 5，IPS Technology |
| Screen Size | 10.1 Inches |
| Aspect Ratio | 16:10 |
| Screen Resolution | Default: 1920×1200，Maximum: 2560×1600 |
| Pixels Per Inch | 299 PPI |
| CPU | |
| Product model | AMD Ryzen 7 8840U |
| # of CPU Cores / # of Threads | 8C / 16T |
| Base Clock | 3.3 GHz |
| Max. Boost Clock | 5.1 GHz |
| AI Performance | 16 TOPS |
| Total Processor Performance | 38 TOPS |
| Total Cache | 24.5 MB |
| Architecture | Zen 4（Hawk Point） |
| Process Size | 4nm |
| TDP | 15-30W |
| GPU | |
| Processor Graphics | AMD Radeon 780M |
| Graphics Frequency | 2700 MHz |
| Compute Units | 12CU |
| Shading Units | 768 |
| Floating-point Performance | 17.82 TFlops（FP16） |
| 8.92 TFlops（FP32） | |
| 556.8 GFlops（FP64） | |
| Pixel Rate | 92.80 GPixel/s |
| Texture Rate | 139.2 GTexel/s |
| Video Memory | Shared Memory |
| HDMI | 7680 x 4320 @ 60Hz |
| DP | 7680 x 4320 @ 60Hz |
| DirectX | DX12 Ultimate |
| OpenGL | 4.6 |
| Storage | |
| Memory | 64GB / 32GB |
| Memory Types | LPDDR5x 6400 MT/s |
| Memory Dual Channel | Quad 32-bit Channels |
| Hard Disk Type | M.2 SSD |
| Hard Disk Interface | M.2（Socket 3）× 2 |
| Supported Specifications | M.2 NVMe 2280 × 1 |
| M.2 NVMe 2230 × 1（Default is Empty, Needs to be Purchased Separately） | |
| Standard Capacity | M.2 NVMe 2280 SSD 2TB (PCIe Gen4) |
| Bus Specification | PCIe 4.0 × 4 |
| Transfer Protocol | NVMe 1.3 / 1.4 |
| Multimedia Support | |
| Audio System | Built-in audio chip, DTS audio |
| Loudspeakers | Built-in 4 Super Linear Speakers |
| Camera | Built-in Camera: 2 Million Pixels, Maximum Resolution: 1612×1212, Super Wide-angle, High Refresh Rate |
| Microphone | Built-in microphone |
| Network Communications | |
| 4G LTE Module | Supports，4G module needs to be purchased separately |
| SIM Card Type：Nano-SIM | |
| 4G Network：TD-LTE，FDD-LTE | |
| 3G Network：WCDMA/TD-SCDMA/CDMA，2G Network：GSM | |
| Supported Frequency Bands： | |
| 2G：GSM900/1800MHz | |
| 3G：WCDMA B1/B8，TD-SCDMA B34/B39，CDMA BC0 | |
| 4G：LTE TDD B34/B38/B39/B40/B41，LTE FDD B1/B3/B5/B8 | |
| Wi-Fi 6 | IEEE 802.11 a/b/g/n/ac/ax, Support 2.4G/5G Dual Frequency Band, Dual Channel Maximum Transmission Rate 2402Mbps |
| MU-MIMO | Supports |
| Bluetooth | 5.2 |
| I/O Interface | |
| Video / Data / Charging | USB4 (40Gbps) × 1 |
| USB 3.2 Gen 2 Type-C × 1 | |
| USB 3.2 Gen 2 Type-A × 2 | |
| Oculink (SFF-8612) × 1, 63Gbps | |
| HDMI 2.1 × 1 | |
| microSD Slot | SD 3.0 Protocol |
| Bus interface: UHS-I | |
| Video Speed Class: V30 | |
| Application Performance Class: A1, Read: 100MB/s | |
| Compatible: microSDHC / microSDXC / microSDUC | |
| microSD Card Slot and SD Card Slot are Mutually Exclusive. Only One Slot Can be Used at a Time. Inserting a Card in One Slot Will Make The Other Slot Invalid | |
| SD Slot | SD 4.0 Protocol |
| Bus interface: UHS-II | |
| Video Speed Class: V90 | |
| Read 312MB/s，Write: 312MB/s | |
| Compatible: SDHC / SDXC / SDUC | |
| microSD Card Slot and SD Card Slot are Mutually Exclusive. Only One Slot Can be Used at a Time. Inserting a Card in One Slot Will Make The Other Slot Invalid | |
| Audio Port | 1×3.5mm Headphone/Microphone Combo Interface, Compatible With Apple Headphones (US Specification) |
| BIOS Reset Port | Supports |
| I/O Device | |
| Power | Power Button With A Fingerprint Sensor |
| Keyboard | QWERTY Keyboard Design，Backlight (2-level Brightness Control) |
| Indicator Lamp | Charging Indicator |
| Running Indicator | |
| CapsLook Indicator | |
| Fan Switch Indicator | |
| TouchPad | Microsoft Precision TouchPad （PTP） |
| Mouse | The Joystick Simulates A Mouse, Requires Switching The Mode Handle/Mouse |
| Joystick | Hall Sensor Sticks, Stepless, Super Linear, No Dead Zone, Sink-in Design, Native Support For Down Pressure Sensitive L3 / R3 |
| Game Accessories Buttons | Analog Triggers |
| Game Function Buttons | Double Silk-printed Legends (ABXY, △○×□, Select, Start, Xbox (Menu)) |
| D-Pad | Siamese Arrow Keys |
| Handle Vibration | Double Vibration Motor |
| Sensor | 6-axis Gyroscope |
| Other Keys | Handle / Mouse Switch Button，2 Custom Physical Buttons |
| Battery | |
| Battery Type | Li-polymer |
| Battery Capacity | 67Wh |
| Battery Life | 3 Hours Of Heavy Use, 6-8 Hours Of Moderate Use, 14 Hours Of Light Use, Depending On The Specific Environment Of Use |
| Appearance | |
| Weight | 1005g |
| Size | 227 × 160 × 23 mm |
| Shell Material | A and C Sides Are Made of 6061 Aluminum-magnesium Alloy, LG-DOW 121H Aviation ABS |
| Shell Color | Rust Tint |
| Covers | Magnetic Suction Type, Can Be Stored Inside The Shell |
| Thermal Design | Active Cooling, Big Fan + Dual Heat Pipe |
| Accessories | |
| GPD WIN Max 2 (2024) × 1 | |
| 100W PD Power Adapter（20V==5A，20V==3.25A）×1 | |
| Supports 100W, c-c Power Cord With E-mark | |
| Warranty Card ×1 | |
| Product Manual ×1 |
