Description
Be the Game Changer
Level up your gaming experience with LG UltraGear™ gaming monitor.
Fluid Gaming Motion
An ultra-fast speed of 165Hz allows gamers to see the next frame quickly and makes images appear smoothly to help the players respond rapidly to opponents and easily aim at the targets.
AMD FreeSync™ Premium
Clearer, Smoother and Faster
With FreeSync™ Premium technology, gamers can experience seamless, fluid movement in hi-resolution and fast-paced games. It virtually reduces screen tearing and stuttering.
Designed to Focus on Gaming
Enhance your gaming experience with new Hexagon design and slim bezel on 3-side. The base can be adjusted to change the tilt of the monitor to help you play game more comfortable.
Set It Up to Your UltraGear™ Suits Your Gaming-style
Gamers can use On-Screen Display and OnScreen Control to easily customize the setting from adjusting basic monitor options to registering ‘User Defined Key’ that user can set the shortcut.
React Faster to Opponents
Reduce input lag with Dynamic Action Sync so it helps gamers catch critical moment in real-time.
Attack First in Dark
Black Stabilizer helps gamers to avoid snipers hiding in the darkest places and quickly escape situations when the flash explodes.
Track Your Frame Rate
Without installing a separate software, you can see your Frames Per Second (FPS) in games by displaying it in the corner of the screen.
Specifications :
| DISPLAY | |
| Size (Inch) | 23.8 |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16:9 |
| Brightness (Min.) | 200 cd/m² |
| Color Gamut (Min.) | NTSC 70% (CIE1931) |
| Color Depth (Number of Colors) | 16.7M |
| Contrast Ratio (Min.) | 1800:1 |
| Response Time | 5ms (GtG at Faster) |
| Viewing Angle (CR≥10) | 178º (R/L), 178º (U/D) |
| Curvature | NO |
| Size (cm) | 60.3 cm |
| Panel Type | VA |
| Pixel Pitch | 0.2739 x 0.2739 mm |
| Brightness (Typ.) | 250 cd/m² |
| Color Gamut (Typ.) | NTSC 72% (CIE1931) |
| Color Bit | 8bit(6bit+FRC) |
| Contrast Ratio (Typ.) | 3000:1 |
| Refresh Rate (Max.) [Hz] | 165 |
| Surface Treatment | Anti-Glare |
| FEATURES | |
| HDR 10 | NO |
| VESA DisplayHDR™ | NO |
| Mini-LED Technology | NO |
| Advanced True Wide Pol. | NO |
| HW Calibration | NO |
| Flicker safe | YES |
| Reader Mode | YES |
| Super Resolution+ | NO |
| MBR (Supported Frequency) | 120, 144, 165Hz |
| AMD FreeSync™ | FreeSync Premium |
| Black Stabilizer | Black Stabilizer |
| Crosshair | YES |
| OverClocking | NO |
| Auto Input Switch | YES |
| PBP | NO |
| Smart Energy Saving | YES |
| Camera | NO |
| Dolby Vision™ | NO |
| HDR Effect | NO |
| Nano IPS™ Technology | NO |
| Color Calibrated in Factory | NO |
| Auto Brightness | NO |
| Picture Mode | Gamer1, Gamer2, FPS, RTS, Vivid, Reader |
| Color Weakness | NO |
| Motion Blur Reduction Tech. | YES |
| NVIDIA G-Sync™ | NO |
| VRR | NO |
| Dynamic Action Sync | YES |
| FPS Counter | YES |
| User Defined Key | YES |
| RGB LED Lighting | NO |
| PIP | NO |
| OSD Language | 17 countries (English, Germanic, French, Spanish, Italian, Swedish, Finnish, Portuguese, Portuguese(brazil), Polish, Russian, Greek, Ukrainian, Chinese, Traditional Chinese, Japanese, Korean) |
| Mic | NO |
| SW APPLICATION | |
| LG Calibration Studio (True Color Pro) | NO |
| OnScreen Control (LG Screen Manager) | YES |
| LG UltraGear™ Studio | NO |
| Dual Controller | NO |
| LG UltraGear™ Control Center | NO |
| CONNECTIVITY | |
| D-Sub | NO |
| HDMI | YES(2ea) |
| HDMI (HDCP Version) | 1.4 |
| HDMI (w/ VRR) | 48~144Hz |
| DP Version | 1.2 |
| DP (w/o Adaptive-Sync) | 56~165Hz |
| Thunderbolt | NO |
| USB-C | NO |
| Daisy Chain | NO |
| USB Downstream Port | NO |
| LAN (RJ-45) | NO |
| Audio In | NO |
| Headphone out | 3-pole (Sound Only) |
| [Location] | Rear |
| DVI-D | NO |
| HDMI Version | 1.4 |
| HDMI (w/o VRR) | 56~144Hz |
| DisplayPort | YES(1ea) |
| DP (HDCP Version) | 1.4 |
| DP (w/ Adaptive-Sync) | 48~165Hz |
| Thunderbolt (Data Transsmission) | NO |
| USB-C (Data Transsmission) | NO |
| USB Upstream Port | NO |
| Built-in KVM | NO |
| SPDIF out (Optical Digital Audio Out) | NO |
| Mic In | NO |
| Line out | NO |
| SOUND | |
| Speaker | NO |
| DTS HP:X | NO |
| Rich Bass | NO |
| Bluetooth Conectivity | NO |
| Maxx Audio | NO |
| POWER | |
| Type | External Power(Adapter) |
| DC Output | 19V , 1.7A |
| Power Consumption (Max.) | 27W |
| Power Consumption (DC Off) | Less than 0.3W |
| AC Input | 100~240V (50/60Hz) |
| Power Consumption (Typ.) | 24W |
| Power Consumption (Sleep Mode) | 0.5W |
| MECHANICAL | |
| Borderless Design | 3-Side Virtually Borderless Design |
| Color (Back Cover) | Black, Pattern + Texture |
| Color (Stand Base) | Black, Texture |
| Tilt | -5/15 Degree |
| Pivot | NO |
| Base Detachable | YES |
| Color (Middle Cabinet) | Black, High Glosh + Texture |
| Color (Stand Body) | Black, Texture |
| Display Position Adjustments | Tilt |
| Down Height | 110.6mm |
| Wall Mountable | 75 x 75 mm |
| OneClick Stand | NO |
| DIMENSIONS/WEIGHT | |
| Dimension with Stand (W x H x D) | 539.5 x 414.2 x 196.0mm |
| Weight without Stand | 2.97kg |
| Pallet Stuffing (20ft/40ft/40ft HC) | 572/1144/1320 |
| Dimension without Stand (W x H x D) | 539.5 x 322.2 x 39mm |
| Weight with Stand | 3.57kg |
| STANDARD | |
| TCO | NO |
| TUV-TYPE | YES |
| TUV-Ergo | NO |
| UL (cUL) | YES |
| EPEAT (USA) | NO |
| Erp | YES |
| BIS (for India) | YES |
| BSMI (for Taiwan) | NO |
| CCC (for china) | YES |
| USB-C (USB-IF) | NO |
| VESA wall mount standard | NO |
| EPA | NO |
| TUV-GS | NO |
| CB | YES |
| FCC-B | YES |
| EPEAT (Germany) | NO |
| CE | YES |
| VCCI (for Japan) | YES |
| KC (for Rep. of Korea) | YES |
| Thunderbolt | NO |
| USB-C (VESA) | NO |
| ACCESSORY | |
| Adapter | YES |
| Power Cord | Depend on Country |
| D-Sub | NO |
| DVI-D | NO |
| HDMI | NO |
| Display Port | YES |
| Thunderbolt | NO |
| USB Type C | NO |
| USB A to B | NO |
| Remote Controller | NO |
| Calibration Report (Paper) | NO |
| Adapter (Color) | Black |
| Power Cord (Color/Length) | Black/1.5m |
| D-Sub (Color/Length) | NO |
| DVI-D (Color/Length) | NO |
| HDMI (Color/Length) | NO |
| Display Port (Color/Length) | Black/1.5m |
| Thunderbolt (Color/Length) | NO |
| USB Type C (Color/Length) | NO |
| USB A to B (Color/Length) | NO |
| Remote Controller (Color) | NO |
