| PANEL SIZE |
23.8” (60cm) |
| ACTIVE DISPLAY AREA (MM) |
527.04(H) x 296.46(V) |
| CURVATURE |
Flat |
| PANEL TYPE |
IPS |
| PANEL RESOLUTION |
1920 x 1080 (FHD) |
| PIXEL PITCH (H X V) |
0.2745(H)x0.2745(V) |
| ASPECT RATIO |
16:09 |
| BRIGHTNESS (NITS) |
300 |
| CONTRAST RATIO |
1000:01:00 |
| DCR |
100000000:1 |
| SIGNAL FREQUENCY |
65.8~136.3 KHz (H) / 48~100 Hz(V) |
| ACTIVATED RANGE |
48 to 100Hz |
| REFRESH RATE |
100Hz |
| RESPONSE TIME |
1ms (MPRT) |
| DYNAMIC REFRESH RATE TECHNOLOGY |
Adaptive sync |
| VIDEO PORTS |
1x HDMI™ (Supports FHD@100Hz as specified in HDMI™ 1.4b) 1x DP (Supports FHD@100Hz as specified in DisplayPort 1.2a) |
| AUDIO PORTS |
1x Earphone out |
| VIEWING ANGLE |
178° (H) / 178° (V) |
| ADOBE RGB / DCI-P3 / SRGB |
85% / 85% / 110% |
| SURFACE TREATMENT |
Anti-glare |
| DISPLAY COLORS |
16.7M |
| POWER TYPE |
External Adaptor 20V 2.25A |
| POWER INPUT |
100~240V, 50/60Hz |
| ADJUSTMENT (TILT) |
-5° ~ 20° |
| KENSINGTON LOCK |
Yes |
| CONTROL |
5-way OSD navigation joystick |
| COLOR BIT |
8 Bits (6 bits + FRC) |
| DIMENSION (W X D X H) |
540.2 x 229.4 x 423 mm 540.2 x 44.5 x 328.2 mm (Without stand) |
| CARTON DIMENSION (W X H X D) |
WW carton: 600x 164 x 409 mm / Outer carton: 615 x 179 x 434 mm |
| FRAMELESS DESIGN |
Yes |
| VESA MOUNTING |
100 x 100 mm |
| WEIGHT (NW / GW) |
3.3kg / 5.0kg without Stand: 2. |
| NOTE |
Display Port: 1920 x 1080 (Up to 100Hz) |
| HDMI™: 1920 x 1080 (Up to 100Hz) |
|
| Adobe RGB, DCI-P3 and sRGB follow CIE1976 Standard |
