Description
- The enlarged copper base surface area helps to achieve ultimate heat exchange with the latest CPU generation.
- Maximize micro-channels to dissipate heat efficiently
- Rotatable water block cap for 270 degree.
- ARGB fan can change the lighting by MSI center.
- Enhanced fan performance to dissipate heat quickly.
- Durable three phase motor of the pump generates minimal vibrations for long-lasting operation.
- Spilt pathway through the radiator rapidly dissipates heat.
SPECIFICATION
| RADIATOR SIZE | 240 mm |
| RADIATOR DIMENSIONS (WXDXH) | 277 x 119.2 x 27mm / 10.91 x 4.69 x 1.06 inches |
| RADIATOR MATERIAL | Aluminum |
| WATER COOLING TUBE MATERIAL | Black Rubber |
| NUMBER OF FANS | 2 |
| FAN DIMENSIONS (WXDXH) | 120 x 120 x 25mm / 4.7 x 4.7 x 0.98 inches |
| FAN AIR FLOW | 25.5~75.04 CFM |
| FAN BEARING | Fluid Dynamic Bearing (FDB) |
| FAN LIFE EXPECTANCY | 50,000 hrs@40℃ |
| FAN RATED CURRENT | 0.25A(Max:0.4A) |
| FAN POWER CONSUMPTION | 3W(Max:4.8W) |
| PWM MODE | YES |
| CABLE LENGTH (PWM CABLE) | 500 mm |
| FAN CONNECTOR | 4-pin |
| FAN LIGHTING | ARGB |
| RGB CONNECTOR | 3-pin + Socket |
| PUMP LIFE EXPECTANCY | 200,000 hours in typical use |
| PUMP NOISE LEVEL | 20 dBA (avg.) |
| PUMP RATED CURRENT | 0.25A (Max: 0.5A) |
| PUMP POWER CONSUMPTION | 3W (Max: 6W) |
| PUMP SPEED | 3000 RPM ± 10% |
| PUMP CONNECTOR | 4-pin |
| COLD PLATE MATERIAL | Copper |
| BLOCK DIMENSIONS (WXDXH) | 41±0.2*47.6±0.2mm |
| INTEL SOCKET SUPPORT | LGA 1150/1151/1155/1156/1200/1700 |
| AMD SOCKET SUPPORT | AM5/AM4 |
| ACCESSORIES | 1 x 1 to 2 Fan PWM cable |
| 1 x Molex 4-Pin to 4-Pin fan cable | |
| 1 x Thermal paste |
