Description
- Supports Nvidia® GeForce RTXTM 40 Series graphics cards
- Full modular design
- Flat cables
- 80 Plus Gold certified for high efficiency
- 100% all Japanese 105oC capacitor
- Active PFC design
- Industrial level protection with OVP,OCP,OPP,OTP, SCP,UVP
- LLC Half Bridge Topology with DC-DC module design
SILENT OPERATION
THE POWER SUPPLY IS CAPABLE OF QUIETLY OPERATING AT ALL TIMES WITHOUT DISTURBANCE.
SAFETY & RELIABILITY
THE POWER SUPPLY IS HERE TO PROVIDE YOUR SYSTEM A WORRY FREE OPERATION UNDER ALL LOADINGS.
SYSTEM BUILD
THE POWER SUPPLY CAN BE EASILY PLACED AND INSTALLED INTO YOUR BUILD.
SPECIFICATION
| EFFICIENCY RATING | 80 PLUS Gold (up to 90%) |
| MODULAR | Yes (full modular) |
| FAN SIZE | 135 mm |
| FAN BEARING | Fluid Dynamic Bearing |
| DIMENSIONS (DXWXH) | 150 x 150 x 86 mm |
| PFC TYPE | Active PFC |
| INPUT VOLTAGE RANGE | 100-240 |
| POWER WATT | 850W |
| POWER EXCURSION | 1700W (*up to 200% of the PSU's rated power for 100s) |
| INPUT FREQUENCY RANGE | 50~60 Hz |
| PROTECTION | OCP / OVP / OPP / OTP / SCP / UVP |
| ATX (24 PIN) | 1 |
| EPS (4+4 PIN) | 2 |
| PCI-E 5.0 (16 PIN) | 1 (600W) |
| PCI-E (6+2 PIN) | 6 |
| SATA (15 PIN) | 8 |
| MOLEX (4 PIN) | 4 |
| FDD (4 PIN) | 1 |
