Description
- Direct heatpipe contact with nickel-plated coating for efficient heat dissipation.
- Stylish and unique top cover design for a personalized look.
- High-performance fan delivering quiet operation with low noise levels.
- ARGB lighting on both top cover and fan: connect to 12V 4-pin for fixed color and then connect 5V 3-pin for synchronized lighting effects.
- Compatible with both Intel and AMD platforms, ensuring easy and straightforward installation.
Specifications:
| Basic | |
| TDP | 190W |
| CPU Socket | Intel LGA: 115X/1200/1700/1851 AMD: AM4/AM5 |
| Product Dimension | 123*65*147mm (L×W×H) |
| Net Weight | 464g |
| Heatpipe | Φ6mm*4 |
| Fan Quantity | 1 |
| Fan Dimension | 120*120*25mm (L×W×H) |
| Bearing Type | Hydraulic Bearing |
| Speed | 800~1800±10% RPM |
| Air Flow (MAX) | 60 CFM |
| Air Pressure (MAX) | 1.66 mmH2O |
| Noise | ≤31 dB(A) |
| Rated Voltage | 12 VDC |
| Rated Current | 0.27 A |
| Power Consumption | 3.24 W |
| Connector | 4-Pin PWM |
| Fan LED Type | ARGB |
| Fan LED Connector | 3-Pin |
| Fan LED Rated Voltage | 5 VDC |
| Fan LED Rated Current | 0.27 A |
| Fan LED Power Consumption | 1.35 W |
