Description
This high-performance CPU air cooler is designed to deliver powerful thermal management for gaming systems, workstations, and high-performance desktops. The heatsink measures 122 mm × 114 mm × 162 mm and features six 6mm heat pipes that efficiently transfer heat away from the CPU for stable and reliable performance. Its C1100 pure copper base with nickel plating ensures excellent heat conductivity while enhancing durability and resistance to corrosion. The cooler is backed by a 3-year warranty for added peace of mind.
For superior airflow and cooling efficiency, the cooler includes two optimized PWM fans. The TL-H12-X28 120mm fan offers high-performance cooling with speeds up to 2150 RPM, delivering an impressive 80.45 CFM airflow and 2.65 mm H₂O air pressure. Despite its powerful output, it maintains a reasonable noise level of 29.4 dBA, ensuring effective cooling without excessive noise. It uses a 4-pin PWM connector for intelligent speed control and an S-FDB V2 bearing for long-lasting, stable operation.
Complementing the main fan is the TL-H12015B slim 120mm fan, designed for improved airflow in tighter spaces. Operating at up to 1900 RPM, it produces 56.36 CFM airflow with 1.58 mm H₂O air pressure, while maintaining a low noise level of 28.4 dBA. Like the primary fan, it features a 4-pin PWM connector and S-FDB V2 bearing, ensuring smooth performance and durability.
With its advanced heat pipe structure, premium copper base, and dual-fan cooling system, this CPU cooler delivers powerful heat dissipation, stable operation, and quiet performance—making it an excellent choice for demanding PC builds.
| Heatsink Dimension | L122 mm x W114 mm x H162 mm |
| Heat pipes | 6mm heatpipe x 6 units |
| Copper Base | C1100 Pure copper nickel plated |
| Warranty | 3 Years |
| TL-H12-X28 Fan Dimension | L120 mm x W120 mm x H28 mm |
| TL-H12-X28 Rated Speed | 2150 RPM±10% (MAX) |
| TL-H12-X28 Noise Level | 29.4 dBA |
| TL-H12-X28 Air Flow | 80.45 CFM (MAX) |
| TL-H12-X28 Air Pressure | 2.65 mm H2O (MAX) |
| TL-H12-X28 Connector | 4 Pin (PWM Fan connector) |
| TL-H12-X28 Bearing Type | S-FDB V2 Bearing |
| TL-H12015B Fan Dimension | L120 mm x W120 mm x H15 mm |
| TL-H12015B Rated Speed | 1900 RPM±10% (MAX) |
| TL-H12015B Noise Level | 28.4 dBA |
| TL-H12015B Air Flow | 56.36 CFM (MAX) |
| TL-H12015B Air Pressure | 1.58 mm H2O (MAX) |
| TL-H12015B Connector | 4 Pin (PWM Fan connector) |
| TL-H12015B Bearing Type | S-FDB V2 Bearing |
